6.1 Overview
Configuration
Operating parameters
* Length
Features
C__65_-EPN
encoder
data 4 byte I
Page 101
- Rotational direction
- Resolution
- Revolutions
32 Bit IN
- Preset adjustment with an acyclic write service
- Scaling of the measuring system
- Max. steps per revolution: 4096
- Max. number of revolutions: 8192
C__65_-EPN
TR-Special
encoder
data 4 byte I
Page 103
- Rotational direction
- Measuring range
- revolutions numerator
- revolutions denominator
32 Bit IN
- Preset adjustment with an acyclic write service
- Scaling of the measuring system
- Scaling of the measuring system, the number of
steps per revolution can be a decimal number
and the number of revolutions any number (not
an exponent of 2).
- Max. steps per revolution: 262144
- Max. number of revolutions: 256000
16
,
17
C__65_-
EPN
+ Cam
encoder
data 4 byte I
Page 105
- Rotational direction
- Measuring range
- revolutions numerator
- revolutions denominator
- Output x, Cam x, Start
- Output x, Cam x, Start
- Preset value 1
- Preset value 2
32 Bit IN
- Preset adjustment with an acyclic write service
- Scaling of the measuring system
- Scaling of the measuring system, the number of
steps per revolution can be a decimal number
and the number of revolutions any number (not
an exponent of 2).
- Max. steps per revolution: 262144
- Max. number of revolutions: 256000
- Hardware inputs for Preset 1 and 2
- Cam output
16
C__65_-EPN
+ SSI
encoder
data 4 byte I
Page 108
- Rotational direction
- Measuring range
- revolutions numerator
- revolutions denominator
- Format SSI-interface
- Code SSI-interface
- Data bits SSI-interface
- Mono time SSI-interface
- Preset value 1
- Preset value 2
32 Bit IN
- Preset adjustment with an acyclic write service
- Scaling of the measuring system
- Scaling of the measuring system, the number of
steps per revolution can be a decimal number
and the number of revolutions any number (not
an exponent of 2).
- Max. steps per revolution: 262144
- Max. number of revolutions: 256000
- Hardware inputs for Preset 1 and 2
- SSI output
* from the bus master perspective
16
Optional, must be supported by the device, see name plate or order
17
Also valid for C__58_-EPN rotary encoders
