Trouble-shooting and diagnostic facilities
© TR-Electronic GmbH 1997, All Rights Reserved Printed in the Federal Republic of Germany
Page 40 of 45 TR - ECE - BA - GB - 0009 - 08 03/04/2010
4.2.2 Extended diagnosis
In addition to the standard DP diagnostic message, the encoder also provides an
extended diagnostic message according to the PNO encoder profile. This message
varies in length depending on the chosen nominal configuration. In the configurations
designated "TR mode", the diagnostic message corresponds to PNO Class 2.
The following pages provide a general overview of the available diagnostic
information. Which individual options your encoder actually supports can be read out
from the device itself.
Byte no. Meaning Class
Byte 7 Length (in bytes) of extended diagnosis 1
Byte 8 Alarms 1
Byte 9 Operating status 1
Byte 10 Encoder type 1
Byte 11-14 Encoder resolution in increments per revolution (rotary)
Encoder resolution in measuring increments (linear)
1
Byte 15-16 Number of resolvable revolutions 1
Byte 17 Additional alarms 2
Byte 18-19 Supported alarms 2
Byte 20-21 Warnings 2
Byte 22-23 Supported warnings 2
Byte 24-25 Profile version 2
Byte 26-27 Software version (firmware) 2
Byte 28-31 Operating hour counter 2
Byte 32-35 Offset value 2
Byte 36-39 Manufacturer's offset value 2
Byte 40-43 Number of increments per revolution 2
Byte 44-47 Measuring length in increments 2
Byte 48-57 Serial number 2
Byte 58-59 Reserved 2
Byte 60-63 Manufacturer-specific diagnostics Optional
4.2.2.1 Alarms
Bit Meaning = 0 = 1
Bit 0 Position error No Yes
Bit 1 Supply voltage faulty No Yes
Bit 2 Current consumption too high No Yes
Bit 3 Diagnosis OK Error
Bit 4 Memory error No Yes
Bit 5 Not applicable
Bit 6 Not applicable
Bit 7 Not applicable
To Next Page
