5 Appendix
5.1 New in firmware versions 4.x opposite 3.x
• The till now optionally available commissioning function is activatable in version
4.x at full downward compatibility any time.
• The reduction is cancelled, that the scaling function can be activated only in
connection with the Class 2 functions. The device then works as Class 1 device
with short diagnostic length and is nevertheless scalable.
• In the TR operation modes the diagnostic length can be limited on the length of
the Class 1 diagnosis.
• If the status byte is activated a limit switch bit with two limit values is available to
supervise the displacement range.
• The information of the rotational speed is scalable in arbitrary steps between 1/1
and 1/100 revolutions per minute.
