Inverter-Charger Current
AC Input Voltage
AC Output Voltage
AC Input Amps
Pass Through Amps
Battery Temperature
Displays the actual current (not an average) passing through the inverter to AC loads when
an AC supply is available, or provided by the inverter when inverting.
This meter displays the actual AC voltage and peak AC voltage supply to the
inverter/charger, measured at the AC Input Hot 1 terminal.
Displays the actual AC Voltage output of the inverter/charger measured at the AC Output
Hot 1 terminal.
Appears only on the RC7GS display. Measures the actual AC amperes passing through
the AC Input Hot 1 terminal.
isplays the actual AC amps passing through the
inverter/charger when an external AC source is supplied. Measured at the AC Input Hot 1
terminal.
This meter displays the external temperature of your battery or battery bank when equipped
with a Battery Temperature Sensor (BTS). The scale is divided into counts, which do not
directly correspond to the Fahrenheit or Celsius temperature scale. A higher reading
indicates a lower temperature.
Appears only on the RC7. D
Pass-thru Amps:
0 Amps AC
Battery Temp
000 counts
AC Input
000 Vac 000 Vpk
AC Output:
000 Vac
AC Input:
0 Amps AC
Inv/Chg Current:
+/- 0 Amps DC
13
Copyright Trace Engineering Co. Inc. Tel (360) 435-8826 Part Number 822-4
5916 195 Street, NE Fax (360)435-2229 Effective: November 1, 1997
Arlington, WA 98223 USA www.traceengineering.com Page
