Overload

High Battery Voltage

Low Battery Voltage

Average Shunt Amps

Battery Voltage

When this message is displayed, the loads on the inverter/charger exceed the maximum

power rating of the unit. Reduce the loads on the inverter and restart it.

This message indicates that the battery voltage is too high. Turn off any other charging

sources to allow the voltage level to drop. The inverter will automatically reset and resume

operating when the battery reaches a safe voltage level. This condition will usually occur

only when an additional charging source is used to charge your battery or battery bank.

The battery voltage has dropped below a safe level. The inverter/charger has shut off to

prevent damage to the batteries. Provide an AC supply and the inverter/charger will

automatically reset and start charging. This error will also occur with the RC7GS when the

Auto Genstart function has been disabled, or the genset will not start.

The RC7 and RC7GS have built-in meters that enable you to monitor inverter charger

activity. In order to view these meters, press and hold the Meter key (Up arrow key) for five

seconds, or until the LCD clears. You can then scroll through the meters by pressing the

Down arrow key. These meter displays are intended for and most useful to service

technicians.

This meter displays the averaged current going through the internal shunt (external shunt if

more than one inverter/charger is used) to and from the batteries.

Displays the current battery voltage level. This meter will be useful for checking the

condition of the batteries or monitoring voltage levels under load.

Meters Display

System Status:

Lobat Start Charge

System Status:

Hibat Stop Charge

Avg Shunt Amps

-/+ 0 Amps DC

Battery:

00.0 Volts DC

System Status:

Oload/Less Load
