Transformer Temperature

FET Temperature

Estimated Battery Capacity

Battery State of Charge

Displays the relative temperature of the Field Effect Transistors, which regulate the output

waveform of the inverter. A higher reading indicates cooler temperatures. This meter is

useful to factory technicians only.

This meter reports the estimated battery amp-hour capacity based upon the average amp-

hours used, and the rate and duration of the charging cycles. Multiply the reading by eight

to arrive at the approximate battery capacity. This is only an approximation, and it will

become more accurate as the number of charge/discharge cycles increase.

Upon installation of the RC7 or RC7GS, the LCD screen will display general-purpose

system-status messages. This is the screen that you return to upon exiting the Setup,

Settings, or Meters menu. These operating messages monitor the battery state-of charge

(SOC), time remaining to run, and time left to charge. It also provides the Gen Start/Stop

switch. B ou can view each of these meters in the

sequence in which they are discussed below .

This meter displays the estimated State-of-Charge (SOC) of the battery or battery bank.

The state of charge is based upon the estimated battery capacity. Because it is damaging

to most batteries to discharge them to less than half of their capacity, this meter estimates

the battery SOC at 0% when the battery amphours remaining has reached half of the

estimated battery capacity. This prevents over-discharging and potential damage to the

batteries.

Operating Display

This meter displays the internal temperature of the inverter/charger’s transformer. The

scale is divided into counts, which do not directly correspond to the Fahrenheit or Celsius

temperature scale. A higher reading indicates a lower temperature. This meter is useful to

service technicians only.

y pressing the Down arrow key, y

FET Temp:

000 counts

Est. Bat. Cap:

00 Amp-hrs(x8)

Bat State Off Chg

00% of Full

Bat State Of Chg



Xformer Temp:

000 counts

5916 195 Street, NE Fax (360)435-2229 Effective: November 1, 1997

Arlington, WA 98223 USA www.traceengineering.com Page


