TracVision M9 User’s Guide
78
Appendix D - Recalibration
Verify the Calibration Score
This section explains how to interpret the calibration score display. Be
sure to verify that the calibration yielded acceptable results. If the
calibration did not yield acceptable results, you will need to restart
recalibration.
Use the flowchart in Figure D-4 to display the calibration score. For
information on interpreting the calibration score, see “Interpreting the
Calibration Score” on page 79.
Figure D-4 Displaying the Calibration Score
Sat B Menu Sat C
Tracking Satellite A
Yes Next Return
Install Satellite?
Yes Next Return
Operations Mode?
Yes Next Return
Get Antenna Status?
Yes Next Return
Control Compass?
Yes Next Return
Set Autocal On/Off?
Yes Next Return
Get Cal Score?
Select “Next” until
“Operations Mode?”
is displayed.
Select “Next” until
“Control Compass?”
is displayed.
To Next Page
