Traeger RANGER - Page 9

traegergrills.com | 9
2
3
4
In this step:
4 A
x 2
B
x 2
C
x 1
F
x 2
In this step:
7 8
In this step:
6
INSTALL LID HANDLE
INSTALL GREASE DRIP TRAY AND BUCKET
INSTALL PORCELAIN-COATED GRILL GRATE
NOTE: Be sure the grease drain spout on the
grease drip tray extends through the opening
in the back of the grill.
IMPORTANT: Always be sure to position
the grease drain bucket under the spout
during use!
1
In this step:
3 A
x 4
B
x 4
C
x 1
D
x 4
E
x 4
INSTALL LEGS
NOTE: Handle hardware is installed
on handle.
T01364_Ranger_OM_EN.indd 9 9/9/19 8:59 AM
