17 Series Mini-Split
Operating Ranges
Cooling Only Operating Range Outdoor Temperature 0 - 115°F (-18.0 - 46.1°C)
Heat Pump Operating Range Outdoor Temperature -4.0 - 75°F (-20.0 - 24°C)
Connection Pipe Requirements
NOTICE
The maximum distance of the connection piping in both height and total length is provided in the
table below. Do not install these units in locations that exceed these specications.
NOTES:
1. The connection pipes should be insulated with proper water-proof insulating material
2. Wall thickness of pipe 0.02-0.04 in (0.5-1.0 mm): bearing pressure 435 PSI (3.0 MPa).
3. Shorter connecting pipe lengths result in greater thermal e󰀩ciency, so it is preferable to reduce
connecting pipe lengths where possible.
4. Refer to the oil trap instructions for specic requirements when there is height di󰀨erence
between the indoor and outdoor unit greater than 20 feet (6m).
Heat Pump
4TXK1709 4TXK1712 4TXK1718 4TXK1724
4MXW1709 4MXW1712 4MXW1718 4MXW1724
Refrigerant Charge (oz.) 24.3 27.5 42.4 52.9
Standard Length ft (m) 25 (7.6)
Additional Refrigerant Charge (oz/ft)
For Piping Beyond Standard Length
0.2 0.5
Outer Diameter
Liquid Pipe in (mm)
Φ 1/4" (6.35)
Gas Pipe in (mm)
Φ 3/8" (9.52) Φ 1/2" (12.7) 5/8" (15.875)
Max Distance
Height ft (m)
32.8 (10)
Length ft (m) 49.2 (15)
65.6 (20) 82 (25)
Minimum Piping Length ft (m) 10 (3)
Compressor Oil Used FW68DA RB68EP FW68DA
Cooling Only
4TYK1709 4TYK1712 4TYK1718 4TYK1724
4MYW1709 4MYW1712 4MYW1718 4MYW1724
Refrigerant Charge (oz.) 18.0 19.4 35.3 42.3
Standard Length ft (m) 25 (7.6)
Additional Refrigerant Charge (oz/ft)
For Piping Beyond Standard Length
0.2
Outer Diameter
Liquid Pipe in (mm)
Φ 1/4" (6.35)
Gas Pipe in (mm)
Φ 3/8" (9.52) Φ 1/2" (12.7) 5/8" (15.875)
Max Distance
Height ft (m)
32.8 (10)
Length ft (m)
49.2 (15)
65.6 (20) 82 (25)
Minimum Piping Length ft (m) 10 (3)
Compressor Oil Used FW68DA
