Trane Technologies 17 Series - Page 36

18K-24K Indoor Units
W
D
H
2
47
7 3/16
5 1/2
7 1/2
1 1/2
Φ2 3/16
Φ2 3/16
3 1/8
6
1 11/16
8 1/8 27 7 5/16
Φ2 3/4
Φ2 3/4
Unit:inc
h
18K
24K
Models WHD
18K 38 1/411 13/16 8 7/8
24K 42 1/2 12 13/16 9 11/16
1 1/2
1 11/1
6
Indoor Unit Dimensions, continued
The dimensions in these drawings are rounded
according to standard measurement.
36
17 Series Mini-Split
