Trane Technologies 4TWX8024 User Manual

38
18-GJ89D1-1E-EN
Control Panel Reinstallation
1. Slide control plate assembly into the control pocket until fully
seated. The control plate should be flush with the outer edge of
the unit.
2. Replace coil panel making sure that the wires are located within
the wire pass-through provided in the panel.
Pass through notch
in coil access door
