Trane Technologies 4TWX8024 - System Charge Adjustments

18-GJ89D1-1E-EN
45
System Charge Adjustments
System Matched with:
Indoor Unit Model No. Outdoor Unit Model No.
Subcooling
Single Compressor
2–Stage HP
TAMXB0B30V31DA
4A6H6024E/G, 4TWX6024E/G
4A6H7024, 4TWX8024
9°
TAMXB0C36V31DA
4A6H6036E/G, 4TWX6036E/G
4A6H7036, 4TWX8036
10°
TAMXB0C48V41DA
4A6H6048E/G, 4TWX6048E/G
4A6H7048, 4TWX8048
8°
Single Compressor
2–Stage AC
TAMXB0B30V31DA
4A7A6024E/G, 4TTX6024E/G
4A7A7024, 4TTX8024
8°
TAMXB0C36V31DA
4A7A6036E/G, 4TTX6036E/G
4A7A7036, 4TTX8036
8°
TAMXB0C48V41DA
4A7A6048E/G, 4TTX6048E/G
4A7A7048, 4TTX8048
8°
Notes:
1. Variable Speed outdoor units must be charged per the outdoor unit instructions.
2. All other matches must be charged per the nameplate charging instructions.
