Field Kit Parts, Specifications, Dimensions, and Components
6 RF-SVN03F-EN
Field Kit Parts, Specifications, Dimensions, and
Components
Field Kit Parts
Prior to installation, open the box and verify that the
following parts are enclosed:
• One (1) BCI-R controller
• Four (4) screws
• One (1) USB service port cable
• Two (2) screws for the USB bulkhead port connector
• One (1) bushing for field wiring
• One (1) USB service port label
• Two (2) 4-wire cable harnesses
– X19051430020 (Voyager III)
– X19051278010 (Voyager II, Odyssey, and Precedent)
• One (1) BCI-R Integration Guide (BAS-SVP09-EN)
Important: Contact
the Trane Parts
Center nearest your
area should there be any damaged or
missing components.
Note: One copy of the
appropriate service literature ships
inside the control panel of each unit.
Specifications
The following table provides specifications and
requirements for the BCI-R controller. All BCI-R controllers
are color-coded red for easy identification.
Table 1.
Storage
Temperature: -44°C to 95°C (-48°F to 203°F)
Relative humidity: Between 5% to 95% (noncondensing)
The BCI-R controller has been designed to withstand the effects of dust and corrosion.
Operating
Temperature: -40°C to 70°C (-40°F to 158°F)
Humidity: Between 5% to 95% (noncondensing)
Power: 24 Vdc ±15%, maximum load 90 mA
Specifications and Requirements
