Trane Technologies Precedent TZJ150A - Dimensions and Weights; Dimensional Data

14
RT-SVX076A-EN
Dimensions and Weights
Dimensional Data
Figure 2. 12.5 to 25 tons ultra high efficiency
87"
[2210]
66"
[1676]
44 3/4"
[1135]
55"
[1398]
123"
[3124]
31 7/8"
[810]
EVAPORATOR SECTION
ACCESS PANEL
CONDENSATE DRAIN
INDOOR TOP PANEL
UNIT CONTROL WIRE
2” (50 MM) DIA. HOLE
UNIT POWER WIRE
2” (50 MM) DIA. HOLE
OUTDOOR TOP PANEL
SERVICE GAUGE PORT ACCESS
1 3/8” (35 MM) DIA. HOLE
2" ELECTRICAL CONNEC
T
I
ON
HORIZONTAL ACCESS
UNIT CONTROL
WIRE
CONTROL BOX SECTION
ACCESS PANEL
COMPRESSOR SECTION
ACCESS PANEL
COIL GUARDS
2" ELECTRICAL CONNECTION
SINGLE POINT POWER
Figure 3. 12.5 to 25 tons ultra high efficiency – downflow airflow supply/return, through-the-base utilities
7"
177 MM
14 3/8"
365 MM
14 7/16"
365MM
40"
1002MM
19 3/8"
488MM
65"
1652MM
73 5/8"
1868MM
8 3/8"
212MM
48"
1223MM
6 5/8''
167 MM
55.0577
[1398.467]
55.2977
[1404.563]
8''
205MM
55 3/8''
1404MM
THROUGH
THE BASE
ELECTRICAL
THROUGH
THE BASE GAS
(Y_J MODELS
ONLY)
