Trane Technologies Precedent TZJ150A - Page 15

RT-SVX076A-EN
15
Figure 4. 12.5 to 25 tons ultra high efficiency – horizontal airflow supply/return
46 1/2''
[1181]
6''
[153]
20''
[508]
25 1/2''
[648]
26 3/4''
[679]
29''
[737]
5 1/4''
[133]
22 3/8''
[570]
18 7/16''
[468]
4 9/16''
[114]
7 15/16''
[202]
5 1/2''
[141]
SUPPLY
RETURN
Figure 5. 12.5 to 25 tons ultra high efficiency – power exhaust
4.4
21.4
7.0
22.7
Dimensions and Weights
