Installation and Configuration: Display Sensor
4. Hold the back plate against the mounting surface and mark the screw locations.
5. Secure the back plate to the mounting surface using the included hardware.
Wiring the Sensor
WARNING
Hazardous Voltage!
Disconnect all electric power, including remote disconnects before servicing. Follow proper
lockout/tagout procedures to ensure the power can not be inadvertently energized. Failure to
disconnect power before servicing could result in death or serious injury.
NOTICE:
Equipment damage!
Applying excessive voltage to the sensor will permanently damage it.
To wire the sensor to the unit controller:
1. Ensure that the wires are connected to the appropriate terminals at the unit controller.
Note: En
sure that the GROUND (terminal 10) and the SIGNAL COMMON (terminal 2) wires
share a common ground with the transformer
2. Insert each wire into the
appropriate location in the terminal block (see the table in Figure 1,
p. 13). Tighten the terminal screw.
Note: T
he wire connections can be made while the terminal block is either on the circuit board,
or removed from it.
3. Perform a pull test to ensure tha
t the wires are properly connected.
4. If you want the sensor to read an external thermistor, reset
the jumper to the external position
as shown in Figure 1, p. 13.
5. If the terminal block was removed from the circ
uit board, attach it to the pins inside the sensor
cover (Figure 1, p. 13).
