Specifications and Agency Compliance
Specifications
Sensor operating temperature From 32°F to 122°F (0°C to 50°C)
Storage temperature From -40°F to 185°F (-40°C to 85°C)
Storage/operating humidity range 5% to 95% relative humidity (RH), noncondensing
Thermistor accuracy 0.2°C at 25°C, 1%
Setpoint functional range
Display sensor: 50°F to 89.6°F (10°C to 32°C)
All other sensors: 45°F to 95°F (7.2°C to 35°C)
Setpoint markings
Setpoint thumb wheel:
• 50°F to 85°F (in 5°F increments) and *, **
• 10°C to 29°C (in 3°C increments) and *, **
Dual setpoint slider:
• 50 to 85ºF (stamped every 5ºF)
• 10 to 29ºC (stamped every 3ºC)
Housing material
Polycarbonate/ABS blend, UV protected, UL 94-5VA flammability rating, suitable for
applic
ation in a plenum
Mounting
Fits a standard 2 in. by 4 in. junction box (vertical mount only). Mounting holes are spaced
3.2 in.
(83 mm) apart on vertical center line. Includes mounting screws for junction box and
w
all anchors for sheetrock walls. Overall dimensions: 2.9 in (74 mm) by 4.7 in. (119 mm)
Resolution (display sensor) 0.125ºF over a range of 60 to 80ºF (15.6 to 26.7°
C); 0.25ºF when outside this range
Accuracy (display sensor) 0.5°F over a range of 55 to 85°F (12.8 to 29.4ºC)
Power consumption (display sensor) <1 VA
Agency Compliance
• United States:
– UL listed: 94, 5 VA Flammability rating;
916, Energy management equipment
– FCC Part 15, Subpart B
• Canada:
– CUL listed: 916, Energy management equipment
• Europe:
–CE marked
