Trane 4TCC4036A1000A - Page 9

18-EB30D1-1G-EN
9
Figure 5. 3.5 — 5 TON MODELS
Model
Height MM/IN
APPROX. CORNER WEIGHT
KG /
LBS
SHIPPING
WIGHT
KG / LBS
TOTAL
UNIT
WEIGHT
KG / LBS
CENTER OF GRAVITY
MM/IN
A W1 W2 W3 W4 B C
4TCC4042
898.53 [35-3/8]
71.8
[158]
47.2 [104]
35.2
[78]
53.6
[118]
254.5
(561)
207.3
(457)
470.0 [18.5] 731.0 [28.8]
4TCC4048
72.0
[159]
45.0 [99]
33.8
[75]
54.4
[120]
252.6
(557)
205.4
(453)
433.0 [17.0] 743.3 [29.3]
4TCC4060
78.0
[172]
46.3 [102]
34.9
[77]
59.0
[130]
265.8
(586)
218.6
(482)
414.0 [16.3] 635.0 [25.0]
4WCC4042
64.4
[142]
47.6 [105]
39.5
[87]
49.9
[110]
248.6
(547.9)
201.4
(444)
449.6 [17.7]
641.8 [25.3]
4WCC4048
1050.93 [41
-
3/8]
68.9
[152]
40.8 [90]
30.8
[68]
52.2
[115]
240.0
(529)
192.8
(425)
414.0 [16.3] 635.0 [25.0
]
4WCC4060
79.4
[175]
47.2 [104]
35.8
[79]
59.9
[132]
269.5
(594)
222.3
(490)
414.0 [16.3]
635.0 [25.0]
1000.13 [39-3/8]
SStteepp22——DDeetteerrmmiinneeUUnniittCClleeaarraanncceess
