Section 1. Safety
This information is intended for use by individuals
possessing adequate backgrounds of electrical and
mechanical experience. Any attempt to repair a central
air conditioning product may result in personal injury
and/or property damage. The manufacture or seller
cannot be responsible for the interpretation of this
information, nor can it assume any liability in connec-
tion with its use.
These units use R-410A refrigerant which operates
at 50 to 70% higher pressures than R-22. Use only
R-410A approved service equipment. Refrigerant
cylinders are painted a “Rose” color to indicate the
type of refrigerant and may contain a “dip” tube to
allow for charging of liquid refrigerant into the sys-
tem. All R-410A systems use a POE oil that readily
absorbs moisture from the atmosphere. To limit this
“hygroscopic” action, the system should remain sealed
whenever possible. If a system has been open to the
atmosphere for more than 4 hours, the compressor oil
must be replaced. Never break a vacuum with air and
always change the driers when opening the system
for component replacement. For specific handling
concerns with R-410A and POE oil reference Retrofit
Bulletins SS-APG006-EN and APP-APG011-EN or
APP-APG012-EN.
UNIT CONTAINS R-410A REFRIGERANT!
R-410A operating pressures exceed the limit of R-22.
Proper service equipment is required. Failure to use
proper service tools may result in equipment damage
or personal injury.
SERVICE
USE ONLY R-410A REFRIGERANT AND
APPROVED POE COMPRESSOR OIL.
LIVE ELECTRICAL COMPONENTS!
During installation, testing, servicing, and trouble-
shooting of this product, it may be necessary to work
with live electrical components. Failure to follow all
electrical safety precautions when exposed to live
electrical components could result in death or serious
injury.
If using existing refrigerant lines make certain that all
joints are brazed, not soldered.
Scroll compressor dome temperatures may be hot. Do
not touch the top of compressor; it may cause minor
to severe burning.
Extreme caution should be exercised when opening
the Liquid Line Service Valve. Turn counterclockwise
until the valve stem just touches the rolled edge. No
torque is required. Failure to follow this warning will
result in abrupt release of system charge and may
result in personal injury and /or property damage.
Table of Contents
Section 1. Safety ...............................................................................................................................................................2
Section 2. Unit Location Considerations ..........................................................................................................................3
Section 3. Unit Preparation ..............................................................................................................................................5
Section 4. Setting the Unit ................................................................................................................................................5
Section 5. Refrigerant Line Considerations ......................................................................................................................6
Section 6. Refrigerant Line Routing .................................................................................................................................8
Section 7. Refrigerant Line Brazing .................................................................................................................................9
Section 8. Refrigerant Line Leak Check .........................................................................................................................11
Section 9. Evacuation .....................................................................................................................................................11
Section 10. Service Valves .............................................................................................................................................12
Section 11. Electrical - Low Voltage ...............................................................................................................................13
Section 12. Electrical - High Voltage ...............................................................................................................................15
Section 13. Start Up .......................................................................................................................................................16
Section 14. System Charge Adjustment .........................................................................................................................17
Section 15. Checkout Procedures and Troubleshooting .................................................................................................22
Important: This is customer property and is to remain with this
unit. Please return to service information pack upon completion
of work.
These instructions do not cover all variations in systems or pro-
vide for every possible contingency to be met in connection with
the installation. Should further information be desired or should
particular problems arise which are not covered sufficiently for
the purchaser’s purposes, the matter should be referred to your
installing dealer or local distributor.
