Trane 4YCC4060E1090 - Page 36

36
18-EB40D1-1C-EN
4YCC4036E1070
EXTERNAL STATIC PRESSURE (IN.WG) Horizontal Airflow [Down Airflow]
Motor Speed
0.0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
Constant
Circulation
CFM
APPROXIMATELY 40-50% COOLING OR HEATING AIRFLOW
WATTS
Cooling - Low
CFM -
1272
(1259)
1243
(1231)
1214
(1202)
1186
(1174)
1154
(1142)
1116
(1105)
1072
(1061)
- - -
WATTS -
352
(354)
361
(363)
372
(374)
382
(384)
392
(394)
404
(406)
416
(418)
- - -
Cooling - Med
CFM - - - -
1349
(1336)
1319
(1306)
1277
(1264)
1242
(1230)
1199
(1187)
1160
(1148)
1124
(1113)
WATTS - - - -
489
(492)
500
(503)
511
(514)
523
(526)
537
(540)
548
(551)
558
(561)
Cooling - High
CFM - - - - -
1326
(1299)
1296
(1270)
1263
(1238)
1225
(1201)
1183
(1159)
1150
(1127)
WATTS - - - - -
516
(519)
527
(530)
539
(542)
552
(555)
566
(569)
575
(578)
Heating - Low
CFM
1185
(1173)
1141
(1130)
1099
(1088)
1055
(1044)
1009
(999)
968
(958)
920
(911)
854
(846)
808
(800)
731
(724)
624
(618)
WATTS
241
(238)
251
(248)
260
(258)
270
(267)
279
(277)
289
(286)
299
(296)
311
(308)
320
(316)
306
(303)
284
(282)
Heating - High
CFM
1386
(1373)
1354
(1340)
1311
(1298)
1276
(1263)
1238
(1225)
1198
(1186)
1164
(1153)
1069
(1058)
805
(797)
689
(682)
596
(590)
WATTS
386
(382)
399
(395)
409
(405)
419
(415)
430
(425)
441
(437)
452
(448)
432
(428)
320
(317)
303
(300)
298
(295)
Note: Cooling airflow must not exceed 1350 CFM due to condensate blowoff.
4YCC4036E1090
EXTERNAL STATIC PRESSURE (IN.WG) Horizontal Airflow [Down Airflow]
Motor Speed
0.0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
Constant
Circulation
CFM
APPROXIMATELY 40-50% COOLING OR HEATING AIRFLOW
WATTS
Cooling - Low
CFM
1288
(-)
1254
(1238)
1225
(1207)
1193
(1176)
1158
(1143)
1117
(1091)
1070
(-)
- - - -
WATTS
340
(-)
348
(348)
357
(357)
366
(366)
375
(375)
385
(385)
395
(-)
- - - -
Cooling - Med
CFM -
1326
(1320)
1300
(1294)
1271
(1263)
1241
(1234)
1201
(1196)
1107
(1102)
- - - -
WATTS -
410
(410)
419
(419)
427
(427)
437
(437)
447
(447)
423
(423)
- - - -
Cooling - High
CFM - - - -
1349
(1336)
1319
(1306)
1277
(1264)
1242
(1230)
1199
(1187)
1160
(1148)
1124
(1113)
WATTS - - - -
489
(492)
500
(503)
511
(514)
523
(526)
537
(540)
548
(551)
558
(561)
Heating - Low
CFM
1292
(1285)
1259
(1252)
1230
(1222)
1199
(1186)
1163
(1148)
1124
(1111)
1071
(1060)
963
(954)
799
(781)
638
(-)
-
WATTS
343
(343)
351
(351)
360
(360)
369
(369)
378
(378)
388
(388)
398
(398)
370
(370)
316
(316)
293
(-)
-
Heating - High
CFM
1367
(1355)
1341
(1326)
1310
(1295)
1282
(1267)
1250
(1235)
1212
(1183)
1075
(1056)
928
(913)
781
(-)
631
(-)
-
WATTS
404
(404)
413
(413)
421
(421)
431
(431)
439
(439)
448
(448)
404
(404)
346
(346)
302
(-)
282
(-)
-
Note: Cooling airflow must not exceed 1350 CFM due to condensate blowoff.
