Trane 5TEM6B02AV21SA - Page 32

32
18-GF79D1-1A-EN
Figure 20. 5TEM6B02AV21SA, 5TEM6B03AV21SA
Top Cap
Snap Tab
Feature
Snap Tab
Feature
Top Cap
Replace 2 screw
s
and wa
t
e
r
d
i
verter
br
a
cket
Remove 2 screws
and water diverter
bracket
Figure 21. 5TEM6D04AV31SA, 5TEM6D05AV41SA
Remove 2 screws
and water diverter
bracket
Snap Tab
Feature
Top Baffle
Assembly
Snap Tab
Feature
Top Baffle
Assembly
Replace 2 screws
and water diverter
bracket
UUnniitt CCoonnvveerrssiioonn IInnssttrruuccttiioonnss
