26 BAS-SVP09B-EN
Object Data Points and Diagnostic Data Points
Analog Input, 71
Exhaust Enable Damper Position Setpoint
Status
Exhaust air damper minimum position to enable
exhaust sequence.
Percent (98)
Analog Input, 74 Space Temperature Cooling Setpoint Input
Cooling temperature setpoint from space sensor
module.
Fahrenheit (64)
Celcius (62)
Analog Input, 75 Space Temperature Heating Setpoint Input
Heating temperature setpoint from space sensor
module.
Fahrenheit (64)
Celcius (62)
Analog Input, 78 Space Temperature Setpoint Local The local space temperature setpoint.
Fahrenheit (64)
Celcius (62)
Analog Input, 79 Dehumidification Capacity Status
Indicates the unit dehumidification capacity being
utilized.
Percent (98)
Analog Input, 80 Cabinet Style Describes the cabinet style of the unit. NA
Analog Input, 81 Cool Type Describes the cooling type installed in the unit. NA
Analog Input, 82 Preheat Type Describes the heating type installed in the unit. NA
Analog Input, 83 Reheat Type Describes the reheat type installed in the unit. NA
Analog Input, 86 Economizer Minimum Position Setpoint Local
Indicates the local economizer minimum position
setpoint.
Percent (98)
Analog Input, 87 Space Temperature Local
The space air temperature measured by a unit-
mounted sensor.
Fahrenheit (64)
Celcius (62)
Analog Input, 88 Unit Energy Demand
Indicates the current heat/cool energy demand of the
unit.
Percent (98)
Analog Input, 89 Supply Fan Type Describes the supply fan type installed in the unit. NA
Analog Input, 90 Exhaust or Return Fan Type
Describes the exhaust or return fan type installed in the
unit.
NA
Analog Input, 91 RTRM Major Version Major software version number of the RTRM module NA
Analog Input, 92 RTRM Minor Version Minor software version number of the RTRM module NA
Analog Input, 93 RTOM Major Version Major software version number of the RTOM module NA
Analog Input, 94 RTOM Minor Version Minor software version number of the RTOM module NA
Analog Input, 95 BCI-R Major Version Major software version number of the BCI-R module NA
Analog Input, 96 BCI-R Minor Version Minor software version number of the BCI-R module NA
Analog Input, 97 RTAM Major Version Major software version number of the RTAM module NA
Analog Input, 98 RTAM Minor Version Minor software version number of the RTAM module NA
Analog Input, 99 RTEM Major Version Major software version number of the RTEM module NA
Analog Input, 100 RTEM Minor Version Minor software version number of the RTEM module NA
Analog Input, 101 RTDM Major Version Major software version number of the RTDM module NA
Analog Input, 102 RTDM Minor Version Minor software version number of the RTDM module NA
Analog Input, 103 RTVM Major Version Major software version number of the RTVM module NA
Analog Input, 104 RTVM Minor Version Minor software version number of the RTVM module NA
Analog Input, 105 RTCM Major Version Major software version number of the RTCM module NA
Analog Input, 106 RTCM Minor Version Minor software version number of the RTCM module NA
Analog Input, 107 Space Static Pressure Setpoint Active Space pressure setpoint currently used for unit control Inches-of-water (58)
Table 5. Analog Value
Object Identifier Object Name Description Units Valid Range
Analog Value, 1 Filter Runtime Hours Setpoint
The setpoint value used by the
filter run hours calculation.
Hours (71) 0 to 10,000
Table 4. Analog Input (continued)
Object Identifier Object Name Description
Units of Measure
IP/SI
