Contents
General Information
Foreword
Warranty
Unit Description
Model Nomenclature
Receiving
Nameplate
Delivery Check
Resolving Shipping Damage
Storage Consideration
Outdoor Storage
Rigging and Handling
Rigging and Handling
Off Loading
Moving to Position On Site
Forlift Trucks
Roller Movement
Installation
Foundation
Erection
Assembly and Installation
External Connection
Frame to Frame Connection, CLCP
Panel to Frame Connection, CLCP
Paneling, CLCP
Vertical Unit / Final Filter / Damper Joining Method
Piping
Start-Up
Start-Up Procedures
Maintenance
Periodic Maintenance Checklist
Maintenance Plan
Trouble Analysis
General
Pulley and Belt
Appendix A-Unit Weight, CLCP
Appendix B-Fans and Arrangement
Appendix C-Filter ad Qty
Appendix D-Typical Wiring Diagram
Safety Recommendations, Maintenance Contract and Training
Pre - Start Up Checklist
General Information
●Foreword
These installations, operation and
maintenance instructions are given as
a guide to good practice in the
installation, commission into service,
operation and periodic maintenance
TM
by the user, of TRANE Quantum Air
Handler. They do not contain full
service procedures necessary for the
continued successful operation of this
equipment; the services of a qualified
technician should be employed
through the medium of a maintenance
contract with a reputable service
company.
●Warranty
Trane's standard warranty covers the
equipment. It does not cover damage
due to misuse, lack of maintenance, or
failure to comply with the manufacturer's
instructions or recommendations.
●Unit Description
TRANE QuantumTM Air Handler are
Central Station Air Handlers designed
for a variety of controlled air application.
The basic unit consists of a fan,
heating and/or cooling coils, filters and
air dampers. See product catalogue for
list of available modules and options.
The TRANE QuantumTM Air Handler are
designed for cooling load conditions
of 1000-65000 nominal CFM. Fans are
double width, double inlet, centrifugal
types with forward curved, backward
curved, and airfoil blade designs.
To insure fan motor assembly stability
the unit ships with shipping brackets
Located between the fan support frame.
These spacers must be removed prior to fan
operation, to assure proper vibration isolation.
Units ship as complete units, sections or
subassemblies. Each section is provided with
a nameplate (label) which includes type of
section, unit serial number, customer tag
number and unit model number.
