Trane CLCP - Page 8

Assembly & Installation
CLCP Paneling
11
10
Assembly & Installation CLCP
INSERTING WEDGE METHODOLOGY
ACCESSORIES
1″×2″×10″WOOD
V-GROOVE HELPS
TO EASE WEDGING
GRROOVE
SPACER
(STICK-ON RUBBER)
2mm
REQUIRED TO
INSERTING WEDGE
2″DIA NYLON-FACE HAMMER
ACCESSORIES
ACCESSORIES TO DISMANTLE & ASSEMBLE CLCP
2″DIA NYLON-FACE
HAMMER
1″×2″×10″
WOOD
PNEUMATIC
BLINDRIVET
TOOL
M8 & M10×200mm
INSERT-BIT
HOLDERS
(MAGNTIC TYPE)
SLIDING-HEAD BAR
CLAMPS(8″OPEING)
AIR/ELECTRIC
DRILL
SCRAPER
(HARD BLADE
PREFERRED)
2 NOS.8″
BLADE LENGTH
SCREWDRIVER
2″DIA NYLON-FACE
HAMMER
AIR/ELECTRIC
DRILL
SCRAPER
(HARD BLADE
PREFERRED)
2 NOS.8″
BLADE LENGTH
SCREWDRIVER
PERSONAL PROTECTION EQUIPMENTS
SAFETY
FEET PROTECTION
ALERT
SAFETY
HAND PROTECTION
ALERT
SAFETY
EYE PROTECTION
ALERT
REMOVING WEDGE METHODOLOGY
ACCESSORIES
REMOVING WEDGE METHODOLOGY
SEQUENCE TO REMOVE WEDGES
1
2
3
4
AFTER WEDGE NO.3
REMOVED GO INSIDE BOX
TO PUSH OFF THE PANEL.
PULL WEDGE-OFF
190mm
LIMITED SPACEFOR TOOLS
TO REMOVE WEDGE
VERTICAL UNIT JOINING METHOD
HEX.HD.BOLT.
M10X35
BREAK POINT
COMMECTOR
HEX.NUT M10
GASKET
SILICON
FINAL FILTER JOINING METHOD
FINAL FIL TER SECTION
FINAL FIL TER
UNIT BASE
HEX.HD.BOLT.M12X35
SILICON
RIVET
GASKET
ANGLE
