Trane EXHF - GEV 6-10 T 60 Hz; 6 and 7,5 T 50 Hz-Front Return;Back Supply

Unit Dimensions and Weights
WSHP-SVX01L-EN 31
Figure 24. GEV 6-10 tons (072-120) 60 Hz; 6 and 7½ tons (072 and 090) 50 Hz—front return/back supply
(a)
(a)NEC requires that the GEV072-300 front return must be a non-ducted return.
39 5/8"
(1006)
ACCESS PANEL FOR
SHEAVES AND BELTS
13 18"
(333)
15 3/4
(400)
20"
(508)
SERVICE
CLEARANCE
42"
(1067)
4 7/8"
(124)
1
(25.4)
31 3/8"
(797)
36 1/4"
(921)
13 1/2"
(343)
46 1/2"
(1181)
36"
(914)
SERVICE
CLEARANCE
62 5/8"
(1591)
B
W.O. "C" NPTI
DRAIN 3/4" NPTI
A
11 1/2"
(292)
1 7/8"
(48)
W.I. "C" NPTI
HIGH VOLTAGE
7/8" (22.2) DIA.
1 5/8"
(41)
5"
(127)
15"
(381)
24 VOLT
1 1/8" (28.6)
22 3/8"
(568)
38 7/8"
(987)
3/4"
(19)
SUPPLY OPENING
1" (25.4) DUCT FLANGE
RETURN AIR
OPENING
Table 17. GEV 6–10 tons (072-120) 60 Hz; 6 and 7½ tons (072 and 090) 50 Hz—front return/back supply
Unit (60 Hz) Unit (50 Hz) A B C
6 ton —
6-5/8 in.
(168 mm)
18-3/8 in.
(467 mm)
1-1/4 in.
(32 mm)
7½ ton 6 ton
6-5/8 in.
(168 mm)
18-3/8 in.
(403 mm)
1-1/4 in.
(32 mm)
10 ton 7½ ton
6-1/2 in.
(165 mm)
18-1/2 in.
(470 mm)
1-1/2 in.
(38 mm)
