Electrical Data
WSHP-SVX01L-EN 69
GEHE/GEVE
018 220-240/50/1 11.1 9.6 54.0 1 15.0 1.53 1/3 1 13.53 20 0.0 0.0
018 220-240/50/1 19.7 9.6 54.0 1 15.0 1.53 1/3 1 24.57 25 4.4 18.1
018 265/60/1 8.5 7.7 35.0 1 10.8 0.80 1/8 1 10.43 15 0.0 0.0
018 265/60/1 15.9 7.7 35.0 1 10.8 0.80 1/8 1 19.87 20 4.0 15.1
018 380-415/50/3 5.2 4.2 28.0 1 6.5 0.95 1/3 1 6.20 15 0.0 0.0
018 380-415/50/3 7.0 3.6 28.0 1 5.6 0.95 1/3 1 8.75 15 4.4 6.1
024 208/60/1 14.9 12.8 58.3 1 20.0 2.10 1/3 1 18.10 30 0.0 0.0
024 208/60/1 17.8 12.8 58.3 1 20.0 2.10 1/3 1 22.22 30 3.3 15.7
024 230/60/1 14.9 12.8 58.3 1 20.0 2.10 1/3 1 18.10 30 0.0 0.0
024 230/60/1 19.5 12.8 58.3 1 20.0 2.10 1/3 1 24.36 30 4.0 17.4
024 220-240/50/1 12.7 11.2 60.0 1 17.5 1.53 1/3 1 15.53 25 0.0 0.0
024 220-240/50/1 24.0 11.2 60.0 1 17.5 1.53 1/3 1 30.04 35 5.4 22.5
024 265/60/1 11.1 9.6 54.0 1 15.0 1.53 1/3 1 13.53 20 0.0 0.0
024 265/60/1 21.5 9.6 54.0 1 15.0 1.53 1/3 1 26.91 30 5.3 20.0
024 208/60/3 9.2 7.7 53.7 1 12.0 1.53 1/3 1 11.16 15 0.0 0.0
024 208/60/3 10.6 7.7 53.7 1 12.0 1.53 1/3 1 13.22 15 3.3 9.0
024 230/60/3 9.8 7.7 53.7 1 12.0 2.10 1/3 1 11.73 15 0.0 0.0
024 230/60/3 12.1 7.7 53.7 1 12.0 2.10 1/3 1 15.18 20 4.0 10.0
024 380-415/50/3 5.2 4.2 28.0 1 6.5 0.95 1/3 1 6.20 15 0.0 0.0
024 380-415/50/3 8.5 4.2 28.0 1 6.5 0.95 1/3 1 10.58 15 5.4 7.5
024 460/60/3 4.6 3.6 28.0 1 5.6 0.95 1/3 1 5.45 15 0.0 0.0
024 460/60/3 7.6 3.6 28.0 1 5.6 0.95 1/3 1 9.50 15 5.3 6.7
030 208/60/1 16.2 14.1 73.0 1 22.0 2.10 1/3 1 19.73 30 0.0 0.0
030 208/60/1 21.8 14.1 73.0 1 22.0 2.10 1/3 1 27.26 30 4.1 19.7
030 230/60/1 16.2 14.1 73.0 1 22.0 2.10 1/3 1 19.73 30 0.0 0.0
030 230/60/1 23.8 14.1 73.0 1 22.0 2.10 1/3 1 29.80 30 5.0 21.7
030 220-240/50/1 19.5 16.7 79.0 1 26.0 2.77 1/2 1 23.65 40 0.0 0.0
030 220-240/50/1 29.9 13.5 72.0 1 21.0 2.77 1/2 1 37.42 40 6.5 27.2
030 265/60/1 12.7 11.2 60.0 1 17.5 1.53 1/3 1 15.53 25 0.0 0.0
030 265/60/1 26.4 11.2 60.0 1 17.5 1.53 1/3 1 33.04 35 6.6 24.9
030 208/60/3 11.0 8.9 58.0 1 13.9 2.10 1/3 1 13.23 20 0.0 0.0
030 208/60/3 13.5 8.9 58.0 1 13.9 2.10 1/3 1 16.85 20 4.1 11.4
030 230/60/3 11.0 8.9 58.0 1 13.9 2.10 1/3 1 13.23 20 0.0 0.0
030 230/60/3 14.7 8.9 58.0 1 13.9 2.10 1/3 1 18.31 20 5.0 12.6
030 380-415/50/3 7.5 5.8 38.0 1 9.0 1.70 1/2 1 8.95 15 0.0 0.0
030 380-415/50/3 10.8 5.8 38.0 1 9.0 1.70 1/2 1 13.46 15 6.5 9.1
030 460/60/3 5.2 4.2 28.0 1 6.5 0.95 1/3 1 6.20 15 0.0 0.0
030 460/60/3 9.2 4.2 28.0 1 6.5 0.95 1/3 1 11.54 15 6.6 8.3
Table 44. Electrical data: Standard static motors, ½–5 tons (continued)
Model
No. Volts
Total
Unit
FLA
Comp
RLA
(ea)
Comp
LRA
(ea)
No. of
Comp.
Cmp
MCC
Blower
Motor
FLA
Blower
Motor
hp
Fan
Motor
Num.
Minimum
Circuit
Ampacity
Maximum
Overcurrent
Protective
Device
Electric
Heat
kW
Electric
Heat
Amps
