RT-SVX096A-EN
39
Table 13. Maximum Refrigerant Charge (continued)
A/TA Mmax
ft
2
m
2
lb-oz
kg
210 19.5 14-0 6.3
220 20.4 14-10 6.6
230 21.4 15-5 6.9
240 22.3 16-0 7.2
250 23.2 16-10 7.5
260 24.2 17-5 7.8
Table 14. Minimum circulation airflow
mc
Qmin
lb-oz
kg
CFM m
3
/h
4-6 2 119 202.7
4-13 2.2 131 223.0
5-4 2.4 143 243.2
5-11 2.6 155 263.5
6-2 2.8 167 283.8
6-9 3 179 304.1
7-0 3.2 191 324.3
7-7 3.4 203 344.6
7-15 3.6 215 364.9
8-6 3.8 227 385.1
8-13 4 238 405.4
9-4 4.2 250 425.7
9-11 4.4 262 445.9
10-2 4.6 274 466.2
10-9 4.8 286 486.5
11-0 5 298 506.8
11-7 5.2 310 527.0
11-14 5.4 322 547.3
12-5 5.6 334 567.6
12-12 5.8 346 587.8
13-3 6 358 608.1
13-10 6.2 370 628.4
14-1 6.4 382 648.6
14-8 6.6 393 668.9
14-15 6.8 405 689.2
15-6 7 417 709.5
15-14 7.2 429 729.7
16-5 7.4 441 750.0
Start-Up
