40
RT-SVX096A-EN
Table 14. Minimum circulation airflow (continued)
mc
Qmin
lb-oz
kg
CFM m
3
/h
16-12 7.6 453 770.3
17-3 7.8 465 790.5
Table 15. Refrigerant charge limit
Model (Tons) mc/kg
TAmin
7.5
1.7（system A）
5.2
8.5
1.95（system A）
6.0
10
2.3（system A）
7.1
12.5
3（system A）
9.2
Table 16. Minimum effective dispersal volume
Mc V
ED
lb-oz
kg
ft
3
m
3
4-6 2 477 13.5
4-13 2.2 525 14.9
5-4 2.4 573 16.2
5-11 2.6 620 17.6
6-2 2.8 668 18.9
6-9 3 716 20.3
7-0 3.2 764 21.6
7-7 3.4 811 23.0
7-15 3.6 859 24.3
8-6 3.8 907 25.7
8-13 4 954 27.0
9-4 4.2 1002 28.4
9-11 4.4 1050 29.7
10-2 4.6 1098 31.1
10-9 4.8 1145 32.4
11-0 5 1193 33.8
11-7 5.2 1241 35.1
Table 16. Minimum effective dispersal volume
(continued)
Mc V
ED
lb-oz
kg
ft
3
m
3
11-14 5.4 1289 36.5
12-5 5.6 1336 37.8
12-12 5.8 1384 39.2
13-3 6 1432 40.5
13-10 6.2 1479 41.9
14-1 6.4 1527 43.2
14-8 6.6 1575 44.6
14-15 6.8 1623 45.9
15-6 7 1670 47.3
15-14 7.2 1718 48.6
16-5 7.4 1766 50.0
16-12 7.6 1813 51.4
17-3 7.8 1861 52.7
Start-Up
