7
STEP 3 - Slide Blower assembly out of unit using
built-in blower support channels and set aside.
Note: Remove the cardboard from the bottom of the
blower. Cut the tie wrap and remove the foam block
located at the motor.
Blower Support
Channel
STEP 4 - Slide the Coil assembly out of unit using
built-in coil support channels and set aside.
Coil Support
Channel
To Next Page
