8
STEP 5 - For extremely tight spaces where the
cabinet needs to be rotated through a small
opening, remove the top panel and all cross
members. Use a manual driver to avoid stripping
screw holes.
Note: Cross Members are removed by rotating
them toward the door opening and then lifting up
and out of the unit.
Note - When carrying the air handler to the
install location, be sure to use approved carrying
procedures shown in Section 5, if needed.
1
2
