WSHP-PRC004-EN32
GECA 012 –
Cooling – I-P
Performance
Data
Tabulated performance data is for cooling at 80.6 F [27 C] DB/66.2 F [19 C] WB entering air at ARI-ISO 13256-1 rated CFM.
Sensible multipliers vs. entering dry bulb are given at ARI-ISO 13256-1 rating CFM. Multipliers must be used to correct performance at conditions
other than those tabulated. Data shown is
BOLD
type is performance and multipliers at ARI-ISO 13256-1 WLHP and GLHP conditions.
RATED GPM: 3.3 MINIMUM CFM: 320 RATED CFM: 400 MAXIMUM CFM: 400
Table PD-7 – 012 Cooling Performance
EWT Total Sens Power Reject LWT Ft. ISO Cap ISO Pwr ISO
F GPM Mbtuh Mbtuh SHR kW EER Mbtuh F Hd CFM Mbtuh kW EER
1.8 14.3 10.7 0.75 0.75 19.0 16.8 62.6 4.1 400 14.3 0.76 18.9
2.3 14.4 10.8 0.75 0.73 19.7 16.9 59.1 6.0 400 14.4 0.74 19.4
2.6 14.4 10.8 0.75 0.72 20.0 16.9 57.7 7.1 400 14.4 0.73 19.6
45 2.9 14.4 10.8 0.75 0.71 20.2 16.9 56.1 8.7 400 14.4 0.73 19.8
3.0 14.4 10.8 0.75 0.71 20.3 16.9 55.8 9.1 400 14.4 0.73 19.8
3.2 14.4 10.8 0.75 0.71 20.4 16.9 55.3 9.9 400 14.4 0.73 19.9
3.5 14.4 10.8 0.75 0.70 20.5 16.9 54.5 11.6 400 14.4 0.73 19.8
1.8 14.0 10.6 0.76 0.83 16.9 16.6 72.5 4.1 400 14.0 0.83 16.8
2.3 14.0 10.6 0.76 0.81 17.4 16.7 68.8 6.0 400 14.0 0.81 17.2
2.6 14.1 10.6 0.76 0.80 17.6 16.7 67.5 7.1 400 14.1 0.81 17.4
55 2.9 14.1 10.7 0.76 0.79 17.9 16.7 66.1 8.7 400 14.1 0.81 17.5
3.0 14.1 10.7 0.76 0.79 17.9 16.7 65.8 9.1 400 14.1 0.80 17.5
3.2 14.1 10.7 0.76 0.78 18.0 16.7 65.2 9.9 400 14.1 0.80 17.5
3.5 14.1 10.7 0.76 0.78 18.1 16.7 64.3 11.6 400 14.1 0.81 17.5
1.8 13.4 10.4 0.77 0.94 14.3 16.2 85.2 4.1 400 13.4 0.95 14.2
2.3 13.5 10.4 0.77 0.91 14.8 16.3 81.5 6.0 400 13.5 0.92 14.7
2.6 13.6 10.4 0.77 0.90 15.0 16.3 80.3 7.1 400 13.6 0.92 14.8
68 2.9 13.6 10.4 0.77 0.89 15.2 16.3 78.9 8.6 400 13.6 0.91 14.9
3.0 13.6 10.4 0.77 0.89 15.2 16.3 78.6 9.0 400 13.6 0.91 15.0
3.2 13.6 10.5 0.77 0.89 15.3 16.3 78.0 9.9 400 13.6 0.91 15.0
3.5 13.6 10.5 0.77 0.88 15.4 16.3 77.1 11.6 400 13.6 0.91 15.0
1.8 13.1 10.2 0.78 1.02 12.8 15.9 93.9 4.1 400 13.1 1.03 12.7
2.3 13.2 10.3 0.78 0.99 13.3 16.0 90.3 6.0 400 13.2 1.00 13.2
2.6 13.2 10.3 0.78 0.98 13.4 16.0 89.1 7.1 400 13.2 0.99 13.3
77 2.9 13.2 10.3 0.78 0.97 13.6 16.0 87.7 8.6 400 13.2 0.99 13.4
3.0 13.2 10.3 0.78 0.97 13.7 16.0 87.4 9.0 400 13.2 0.99 13.4
3.2 13.2 10.3 0.78 0.96 13.7 16.0 86.9 9.8 400 13.2 0.98 13.5
3.5 13.3 10.3 0.78 0.96 13.8 16.0 85.9 11.6 400 13.3 0.98 13.5
1.8 12.7 10.0 0.79 1.11 11.4 15.6 102.6 4.1 400 12.7 1.11 11.4
2.3 12.8 10.1 0.79 1.07 11.9 15.7 99.1 6.0 400 12.8 1.08 11.8
2.6 12.8 10.1 0.79 1.06 12.1 15.7 97.9 7.1 400 12.8 1.07 11.9
86 2.9 12.8 10.1 0.79 1.05 12.2 15.7 96.5 8.6 400 12.8 1.07 12.0
3.0 12.8 10.1 0.79 1.05 12.3 15.7 96.2 9.0 400 12.8 1.06 12.1
3.2 12.8 10.1 0.79 1.04 12.3 15.7 95.7 9.8 400 12.8 1.06 12.1
3.5 12.9 10.1 0.79 1.04 12.4 15.7 94.8 11.5 400 12.9 1.06 12.1
1.8 12.2 9.9 0.81 1.19 10.3 15.3 111.3 3.6 400 12.2 1.20 10.2
2.3 12.3 9.9 0.80 1.16 10.7 15.4 107.9 5.3 400 12.3 1.16 10.6
2.6 12.4 9.9 0.80 1.14 10.8 15.4 106.6 6.2 400 12.4 1.15 10.7
95 2.9 12.4 9.9 0.80 1.13 11.0 15.4 105.3 7.6 400 12.4 1.15 10.8
3.0 12.4 9.9 0.80 1.13 11.0 15.4 105.0 7.9 400 12.4 1.14 10.8
3.2 12.4 9.9 0.80 1.12 11.0 15.4 104.5 8.6 400 12.4 1.14 10.9
3.5 12.4 9.9 0.80 1.12 11.1 15.4 103.6 10.2 400 12.4 1.14 10.9
1.8 11.8 9.7 0.82 1.29 9.1 14.9 121.0 3.6 400 11.8 1.29 9.1
2.3 11.9 9.7 0.82 1.25 9.5 15.0 117.8 5.3 400 11.9 1.26 9.4
2.6 11.9 9.7 0.82 1.24 9.6 15.0 116.4 6.2 400 11.9 1.25 9.5
105 2.9 11.9 9.7 0.82 1.23 9.7 15.0 115.1 7.5 400 11.9 1.24 9.6
3.0 11.9 9.7 0.82 1.22 9.7 15.0 114.8 7.9 400 11.9 1.24 9.6
3.2 11.9 9.7 0.82 1.22 9.8 15.0 114.3 8.6 400 11.9 1.24 9.7
3.5 11.9 9.7 0.81 1.21 9.9 15.0 113.4 10.1 400 11.9 1.23 9.7
1.8 11.2 9.4 0.84 1.40 8.0 14.5 131.3 3.5 400 11.2 1.41 8.0
2.3 11.3 9.5 0.84 1.37 8.3 14.6 128.0 5.2 400 11.3 1.38 8.2
2.6 11.4 9.5 0.84 1.36 8.4 14.6 126.7 6.2 400 11.4 1.37 8.3
115 2.9 11.4 9.5 0.84 1.34 8.5 14.6 125.3 7.5 400 11.4 1.36 8.4
3.0 11.4 9.5 0.84 1.34 8.5 14.6 125.0 7.9 400 11.4 1.35 8.4
3.2 11.4 9.5 0.84 1.33 8.5 14.6 124.4 8.6 400 11.4 1.35 8.4
3.5 11.4 9.5 0.83 1.33 8.6 14.6 123.7 10.1 400 11.4 1.35 8.5
1.8 11.0 9.3 0.85 1.45 7.5 14.3 136.2 3.5 400 11.0 1.46 7.5
2.3 11.0 9.3 0.85 1.42 7.8 14.3 132.9 5.2 400 11.0 1.43 7.7
2.6 11.1 9.4 0.85 1.41 7.9 14.4 131.6 6.2 400 11.1 1.42 7.8
120 2.9 11.1 9.4 0.84 1.39 8.0 14.4 130.2 7.5 400 11.1 1.41 7.9
3.0 11.1 9.4 0.84 1.39 8.0 14.4 129.9 7.8 400 11.1 1.41 7.9
3.2 11.1 9.4 0.84 1.39 8.0 14.4 129.3 8.6 400 11.1 1.40 7.9
3.5 11.1 9.4 0.84 1.38 8.1 14.4 128.6 10.1 400 11.1 1.40 7.9
