General Data
Table GD-1 – Physical Data (GECA 006-009)
Model: GECA 006-009 006 009
Unit Size Length of cabinet (in) [mm] 48 or 63 [1219 or 1600] 48 or 63 [1219 or 1600]
Height (in) [mm] 25 or 22 1/2 [635 or 571] 25 or 22 1/2 [635 or 571]
Width (in) [mm] 12 [305] 12 [305]
Compressor Type Rotary Rotary
R-22 Refrigerant (lbs) [kg] Heating and Cooling 1.19 [.54] 1.22 [.55]
Cooling Only 1.06 [.48] 1.16 [.53]
Hot Gas Reheat n/a 1.375 [.62]
Approximate Weight without Pallet (lbs) [kg] Unit 192 [87.1] 204 [92.5]
Chassis Only 144 [653] 156 [70.8]
Approximate Weight with Pallet (lbs) [kg] Unit 222 [100.7] 234 [106]
Chassis Only 174 [78.9] 186 [84.4]
Filter Size (standard height - 25" [635 mm]) 1 x 10 x 32 3/8 [25.4 x 254 x 822] 1 x 10 x 32 3/8 [25.4 x 254 x 822]
Filter Size (low height - 22 1/2" [571 mm]) 1 x 7 3/4 x 30 5/8 [25.4 x 197 x 779] 1 x 7 3/4 x 30 5/8 [25.4 x 197 x 779]
Blower Wheel Size (in) [mm] (2) 5 1/4 x 8 1/8 [133 x 206] (2) 5 1/4 x 8 1/8 [133 x 206]
Table GD-2 – Physical Data (GECA 012-015)
Model: GECA 012-015 012 015
Unit Size Length of cabinet (in) [mm] 48 or 63 [1219 or 1600] 48 or 63 [1219 or 1600]
Height (in) [mm] 25 or 22 1/2 [635 or 571] 25 or 22 1/2 [635 or 571]
Width (in) [mm] 12 [305] 12 [305]
Compressor Type Rotary Rotary
R-22 Refrigerant (lbs) [kg] Heating and Cooling 1.75 [.79] 2.44 [1.1]
Cooling Only 1.5 [.68] 1.88 [.85]
Hot Gas Reheat n/a n/a
Approximate Weight without Pallet (lbs) [kg] Unit 203 [92.1] 210 [92.3]
Chassis Only 155 [70.3] 162 [73.5]
Approximate Weight with Pallet (lbs) [kg] Unit 233 [106] 240 [99.8]
Chassis Only 185 [83.9] 192 [87.1]
Filter Size (standard height - 25" [635 mm]) 1 x 10 x 32 3/8 [25.4 x 254 x 822] 1 x 10 x 32 3/8 [25.4 x 254 x 822]
Filter Size (low height - 22 1/2" [571 mm]) 1 x 7 3/4 x 30 5/8 [25.4 x 197 x 779] 1 x 7 3/4 x 30 5/8 [25.4 x 197 x 779]
Blower Wheel Size (in) [mm] (2) 5 1/4 x 8 1/8 [133 x 206] (2) 5 1/4 x 8 1/8 [133 x 206]
