WSHP-PRC004-EN4
Model Number
Description
DIGITS 1-3: UNIT CONFIGURATION
GEC = General Efficiency Console
DIGIT 4: DEVELOPMENT SEQUENCE A
DIGITS 5-7: NOMINAL SIZE (MBH)
006 = 6.0 MBH
009 = 9.0 MBH
012 = 12.0 MBH
015 = 15.0 MBH
DIGIT 8: VOLTAGE (Volts/Hz/Phase)
6 = 220-240/50/1
DIGIT 9: HEAT EXCHANGER
1 = Copper Water Coil
2 = Cupro-nickel Water Coil
DIGIT 10: DESIGN SEQUENCE
A = First Design
DIGIT 11: REFRIGERATION CIRCUIT
0 = Heating and Cooling Circuit
2 = Heating and Cooling Circuit w/ Hot Gas
Reheat
A = Cooling ONLY Circuit
C = Cooling ONLY Circuit w/ Hot Gas Reheat
DIGIT 12: BLOWER CONFIGURATION
1 = Standard Blower
DIGIT 13: CUSTOMER CHANNEL
1 = Boiler / Tower Design
2 = Geothermal Design
5 = International Design
DIGIT 14: OPEN DIGIT
0 = Standard Design
DIGIT 15: SUPPLY-AIR ARRANGEMENT
0 = Standard Supply-Air Arrangement
DIGIT 16: RETURN-AIR ARRANGEMENT
0 = Standard Return-Air Arrangement
DIGIT 17: CONTROL TYPES
0 = Basic 24V Controls
D = Deluxe 24V Controls
C = Tracer ZN.510 Controls
A = TUC Stand-alone Controls
T = TUC/ICS Control
DIGIT 18: T’STAT/SENSOR LOCATION
0 = Wall Mounted Location
1 = Unit Mounted Location with Standard
Entry
2 = Unit Mounted Location with Keylock Entry
DIGIT 19: FAULT SENSORS
0 = No Fault Sensor
1 = Condensate Overflow Sensor
2 = Filter Maintenance Timer
3 = Condensate Overflow and Filter
Maintenance Timer
4 = Fan Status Sensor
5 = Dirty Filter Sensor
6 = Condensate Overflow and Fan Status
Sensor
7 = Condensate Overflow and Dirty Filter
Sensor
8 = Fan Status and Dirty Filter Status Sensor
9 = Fan Status, Dirty Filter Status and
Condensate Overflow Sensor
DIGIT 20: TEMPERATURE SENSOR
0 = No Additional Temperature Sensor
1 = Entering Water Sensor
2 = Return-Air/Mixed-Air Temperature Sensor
3 = Entering Water/Mixed-Air
Temperature Sensor
DIGIT 21: NIGHT SETBACK
0 = No Night Setback Relay
N = Night Setback Relay
DIGIT 22: ELECTRIC HEAT OPTION
0 = No Electric Heat
2 = Boilerless Control/Electric Heat (minimum)
3 = Boilerless Control/Electric Heat
(maximum)
DIGIT 23: UNIT MOUNTED DISCONNECT
0 = No Unit Mounted Disconnect
A = Power Cord/Receptacle Box Disconnect
B = Power Cord/Receptacle Box Disconnect
with Circuit Breaker
DIGIT 24: FILTER TYPE
0 = No Filter (Chassis ONLY)
1 = 1-inch [25.4 mm] Throwaway Filter
DIGIT 25: ACOUSTIC ARRANGEMENT
0 = Sound Attenuation Package
DIGIT 26: FACTORY CONFIGURATION
0 = Standard Factory Configuration (chassis,
cabinet, and subbase)
1 = Chassis ONLY
2 = Low Height Factory Configuration
(chassis, cabinet, and subbase)
3 = Extended Length Factory Configuration
(chassis, cabinet, and subbase)
DIGIT 27: PAINT COLOR
0 = No Paint Selection Available (chassis
ONLY)
1 = Deluxe Beige
2 = Cameo White
3 = Soft Dove
DIGIT 28: OUTSIDE AIR OPTION
0 = No Outside Air
1 = Outside Air Opening
2 = Motorized Outside Air Option (2-position)
DIGIT 29: PIPING ARRANGEMENT
L = Left Hand Piping Arrangement
R = Right Hand Piping Arrangement
2 = Left Hand Piping Arrangement with
Internal Mounted Loop Pump Kit
3 = Right Hand Piping with Internal Mounted
Loop Pump Kit
DIGITS 30-36: DOES NOT APPLY TO THE
CONSOLE PRODUCT
0000000 = Digits 30-36 Does NOT Apply to
the Horizontal/ Vertical Products
Water-Source Comfort System
GEC A 012 6 1 A 0 1 1 0 0 0 D 0 1 0 N 0 0 1 0 0 1 0 L 000000
1-3 4 5-7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30-36
