WSHP-PRC004-EN34
GECA 012 –
Heating – I-P
Performance
Data
Tabulated performance data is tabulated for heating at 68 F [20 C] DB entering air at ARI-ISO 13256-1 rated CFM.
Multipliers must be used to correct performance at conditions other than those tabulated. Data shown in
BOLD
type is performance and
multipliers at ARI-ISO 13256-1 WLHP and GLHP conditions.
RATED GPM: 3.3 MINIMUM CFM: 320 RATED CFM: 400 MAXIMUM CFM: 400
Table PD-8 – 012 Heating Performance
Htg Cap Absorb Power Ft. ISO Cap ISO Pwr ISO
EWT GPM Mbtuh Mbtuh kW COP LWT Hd CFM Mbtuh kW COP
1.8 7.4 5.5 0.75 2.9 16.8 4.1 400 7.4 0.76 2.9
2.3 7.9 6.0 0.77 3.0 18.8 6.1 400 7.9 0.78 3.0
2.6 8.1 6.2 0.78 3.0 19.6 7.1 400 8.1 0.79 3.0
25 2.9 8.4 6.5 0.80 3.1 20.5 8.7 400 8.4 0.81 3.0
3.0 8.5 6.5 0.80 3.1 20.7 9.1 400 8.5 0.82 3.0
3.2 8.6 6.7 0.80 3.1 21.1 9.9 400 8.6 0.82 3.1
3.5 8.8 6.9 0.81 3.2 21.6 11.6 400 8.8 0.84 3.1
1.8 8.6 6.7 0.80 3.2 26.0 4.1 400 8.6 0.80 3.1
2.3 9.2 7.2 0.82 3.3 28.0 6.1 400 9.2 0.83 3.2
2.6 9.4 7.4 0.83 3.3 28.8 7.1 400 9.4 0.84 3.3
35 2.9 9.7 7.6 0.84 3.4 29.7 8.7 400 9.7 0.86 3.3
3.0 9.7 7.7 0.85 3.4 29.9 9.1 400 9.7 0.86 3.3
3.2 9.9 7.8 0.85 3.4 30.3 9.9 400 9.9 0.87 3.3
3.5 10.1 8.1 0.86 3.4 30.8 11.6 400 10.1 0.89 3.3
1.8 10.3 8.2 0.88 3.5 36.0 4.1 400 10.3 0.88 3.4
2.3 10.7 8.6 0.89 3.5 37.7 6.0 400 10.7 0.90 3.5
2.6 10.8 8.7 0.90 3.5 38.3 7.1 400 10.8 0.91 3.5
45 2.9 11.0 8.9 0.90 3.6 38.9 8.7 400 11.0 0.92 3.5
3.0 11.1 8.9 0.91 3.6 39.1 9.1 400 11.1 0.92 3.5
3.2 11.2 9.0 0.91 3.6 39.3 9.9 400 11.2 0.93 3.5
3.5 11.3 9.2 0.92 3.6 39.8 11.6 400 11.3 0.94 3.5
1.8 11.5 9.4 0.93 3.7 44.8 4.1 400 11.5 0.93 3.6
2.3 12.0 9.8 0.94 3.7 46.7 6.0 400 12.0 0.95 3.7
2.6 12.2 9.9 0.95 3.7 47.3 7.1 400 12.2 0.96 3.7
55 2.9 12.4 10.1 0.96 3.8 48.1 8.7 400 12.4 0.98 3.7
3.0 12.4 10.2 0.96 3.8 48.2 9.1 400 12.4 0.98 3.7
3.2 12.5 10.3 0.97 3.8 48.5 9.9 400 12.5 0.99 3.7
3.5 12.7 10.5 0.98 3.8 49.0 11.6 400 12.7 1.00 3.7
1.8 13.2 10.9 0.99 3.9 56.1 4.1 400 13.2 1.00 3.9
2.3 13.7 11.4 1.02 4.0 58.2 6.0 400 13.7 1.02 3.9
2.6 13.9 11.6 1.03 4.0 59.0 7.1 400 13.9 1.04 3.9
68 2.9 14.2 11.9 1.04 4.0 59.9 8.6 400 14.2 1.05 4.0
3.0 14.3 11.9 1.04 4.0 60.0 9.0 400 14.3 1.06 4.0
3.2 14.4 12.0 1.05 4.0 60.4 9.9 400 14.4 1.06 4.0
3.5 14.7 12.3 1.06 4.1 61.0 11.6 400 14.7 1.08 4.0
1.8 14.4 12.0 1.04 4.0 63.9 4.1 400 14.4 1.05 4.0
2.3 15.0 12.5 1.07 4.1 66.2 6.0 400 15.0 1.08 4.1
2.6 15.2 12.8 1.08 4.1 67.1 7.1 400 15.2 1.09 4.1
77 2.9 15.6 13.1 1.09 4.2 68.0 8.6 400 15.6 1.11 4.1
3.0 15.6 13.2 1.10 4.2 68.2 9.0 400 15.6 1.11 4.1
3.2 15.8 13.3 1.10 4.2 68.6 9.8 400 15.8 1.12 4.1
3.5 16.1 13.6 1.11 4.2 69.2 11.6 400 16.1 1.14 4.1
1.8 15.6 13.1 1.09 4.2 71.6 4.1 400 15.6 1.10 4.2
2.3 16.2 13.7 1.12 4.2 74.1 6.0 400 16.2 1.13 4.2
2.6 16.5 14.0 1.13 4.3 75.1 7.1 400 16.5 1.15 4.2
86 2.9 16.9 14.4 1.15 4.3 76.1 8.6 400 16.9 1.17 4.2
3.0 17.0 14.4 1.15 4.3 76.3 9.0 400 17.0 1.17 4.3
3.2 17.2 14.6 1.16 4.3 76.7 9.8 400 17.2 1.18 4.3
3.5 17.5 14.9 1.18 4.4 77.4 11.5 400 17.5 1.20 4.3
Table 9 – Fan Correction Factors – Model GECA 012
Entering Cooling Sensible Cooling Input Heating Heating Input
CFM Capacity Capacity Watts Capacity Watts
333 0.969 0.942 0.990 0.985 1.047
400 1.000 1.000 1.000 1.000 1.000
