WSHP-PRC004-EN36
GECA 015 –
Cooling – I-P
Performance
Data
Tabulated performance data is for cooling at 80.6 F [27 C] DB/66.2 F [19 C] WB entering air at ARI-ISO 13256-1 rated CFM.
Sensible multipliers vs. entering dry bulb are given at ARI-ISO 13256-1 rating CFM. Multipliers must be used to correct performance at conditions
other than those tabulated. Data shown is
BOLD
type is performance and multipliers at ARI-ISO 13256-1 WLHP and GLHP conditions.
RATED GPM: 3.6 MINIMUM CFM: 400 RATED CFM: 480 MAXIMUM CFM: 480
Table PD-10 – 015 Cooling Performance
EWT Total Sens Power Reject LWT Ft. ISO Cap ISO Pwr ISO
F GPM Mbtuh Mbtuh SHR kW EER Mbtuh F Hd CFM Mbtuh kW EER
2.5 15.9 11.9 0.75 0.84 18.9 19.3 59.5 3.5 425 15.9 0.85 18.8
3.0 16.0 11.9 0.75 0.82 19.4 19.3 57.4 4.8 425 16.0 0.83 19.2
3.5 16.0 11.9 0.74 0.81 19.8 19.4 55.6 6.1 425 16.0 0.82 19.5
45 3.7 16.0 11.9 0.74 0.80 20.0 19.4 55.0 6.8 425 16.0 0.82 19.6
4.0 16.0 11.9 0.74 0.80 20.2 19.4 54.4 7.6 425 16.0 0.81 19.7
4.2 16.1 11.9 0.74 0.79 20.3 19.4 53.9 8.4 425 16.1 0.81 19.8
4.5 16.1 11.9 0.74 0.79 20.4 19.5 53.5 9.2 425 16.1 0.81 19.8
2.5 15.6 11.7 0.75 0.93 16.8 19.0 69.4 3.6 425 15.6 0.93 16.7
3.0 15.6 11.7 0.75 0.91 17.2 19.1 67.3 4.8 425 15.6 0.92 17.0
3.5 15.7 11.7 0.75 0.89 17.5 19.1 65.6 6.1 425 15.7 0.91 17.3
55 3.7 15.7 11.7 0.75 0.89 17.7 19.1 64.9 6.8 425 15.7 0.90 17.3
4.0 15.7 11.7 0.75 0.88 17.8 19.1 64.3 7.6 425 15.7 0.90 17.4
4.2 15.7 11.8 0.75 0.88 17.9 19.2 63.8 8.3 425 15.7 0.90 17.5
4.5 15.7 11.8 0.75 0.87 18.0 19.2 63.4 9.2 425 15.7 0.90 17.5
2.5 15.1 11.5 0.76 1.04 14.5 18.6 82.4 3.5 425 15.1 1.04 14.5
3.0 15.1 11.5 0.76 1.02 14.8 18.6 80.1 4.7 425 15.1 1.03 14.7
3.5 15.2 11.5 0.76 1.01 15.0 18.7 78.4 6.1 425 15.2 1.02 14.8
68 3.7 15.2 11.6 0.76 1.00 15.1 18.7 77.7 6.8 425 15.2 1.02 14.9
4.0 15.2 11.6 0.76 1.00 15.2 18.7 77.1 7.6 425 15.2 1.02 14.9
4.2 15.2 11.6 0.76 1.00 15.3 18.7 76.6 8.3 425 15.2 1.02 15.0
4.5 15.2 11.6 0.76 0.99 15.4 18.8 76.1 9.1 425 15.2 1.02 15.0
2.5 14.7 11.3 0.77 1.13 13.0 18.3 91.2 3.5 425 14.7 1.13 13.0
3.0 14.7 11.4 0.77 1.11 13.3 18.3 88.9 4.7 425 14.7 1.12 13.2
3.5 14.8 11.4 0.77 1.10 13.5 18.4 87.2 6.1 425 14.8 1.11 13.3
77 3.7 14.8 11.4 0.77 1.09 13.6 18.4 86.5 6.8 425 14.8 1.11 13.4
4.0 14.8 11.4 0.77 1.09 13.7 18.4 85.9 7.5 425 14.8 1.11 13.4
4.2 14.9 11.4 0.77 1.08 13.7 18.4 85.4 8.3 425 14.9 1.10 13.5
4.5 14.9 11.4 0.77 1.08 13.8 18.4 85.0 9.1 425 14.9 1.10 13.5
2.5 14.3 11.2 0.78 1.22 11.7 17.9 99.9 3.5 425 14.3 1.23 11.6
3.0 14.3 11.2 0.78 1.20 11.9 17.9 97.7 4.7 425 14.3 1.21 11.8
3.5 14.4 11.2 0.78 1.19 12.1 18.0 96.0 6.1 425 14.4 1.20 12.0
86 3.7 14.4 11.2 0.78 1.18 12.2 18.0 95.4 6.8 425 14.4 1.20 12.0
4.0 14.4 11.2 0.78 1.18 12.3 18.0 94.8 7.5 425 14.4 1.20 12.1
4.2 14.4 11.2 0.78 1.17 12.3 18.0 94.3 8.3 425 14.4 1.19 12.1
4.5 14.5 11.3 0.78 1.17 12.4 18.0 93.8 9.1 425 14.5 1.19 12.1
2.5 13.8 11.0 0.79 1.32 10.5 17.5 108.6 3.0 425 13.8 1.32 10.5
3.0 13.9 11.0 0.79 1.30 10.7 17.5 106.4 4.1 425 13.9 1.31 10.6
3.5 14.0 11.0 0.79 1.28 10.9 17.6 104.8 5.2 425 14.0 1.30 10.8
95 3.7 14.0 11.0 0.79 1.28 10.9 17.6 104.2 5.8 425 14.0 1.29 10.8
4.0 14.0 11.1 0.79 1.27 11.0 17.6 103.6 6.5 425 14.0 1.29 10.9
4.2 14.0 11.1 0.79 1.27 11.1 17.6 103.1 7.1 425 14.0 1.29 10.9
4.5 14.0 11.1 0.79 1.26 11.1 17.6 102.7 7.8 425 14.0 1.28 10.9
2.5 13.3 10.8 0.81 1.43 9.3 17.0 118.3 3.0 425 13.3 1.44 9.3
3.0 13.4 10.8 0.81 1.41 9.5 17.0 116.1 4.1 425 13.4 1.42 9.4
3.5 13.4 10.8 0.81 1.39 9.6 17.1 114.6 5.2 425 13.4 1.40 9.6
105 3.7 13.5 10.8 0.81 1.39 9.7 17.1 113.9 5.8 425 13.5 1.40 9.6
4.0 13.5 10.8 0.80 1.38 9.8 17.1 113.4 6.5 425 13.5 1.40 9.7
4.2 13.5 10.9 0.80 1.37 9.8 17.1 112.9 7.1 425 13.5 1.39 9.7
4.5 13.5 10.9 0.80 1.37 9.9 17.1 112.5 7.8 425 13.5 1.39 9.7
2.5 12.8 10.5 0.82 1.53 8.4 16.4 128.5 3.0 425 12.8 1.53 8.3
3.0 12.8 10.5 0.82 1.51 8.5 16.5 126.3 4.0 425 12.8 1.52 8.5
3.5 12.9 10.5 0.82 1.49 8.6 16.5 124.6 5.2 425 12.9 1.50 8.6
115 3.7 12.9 10.5 0.82 1.49 8.7 16.6 123.9 5.8 425 12.9 1.50 8.6
4.0 12.9 10.5 0.82 1.48 8.7 16.6 123.3 6.4 425 12.9 1.50 8.6
4.2 12.9 10.6 0.82 1.48 8.8 16.6 122.8 7.1 425 12.9 1.50 8.7
4.5 13.0 10.6 0.81 1.47 8.8 16.6 122.5 7.8 425 13.0 1.49 8.7
2.5 12.5 10.3 0.83 1.58 7.9 16.2 133.4 3.0 425 12.5 1.59 7.9
3.0 12.5 10.4 0.83 1.56 8.0 16.2 131.2 4.0 425 12.5 1.57 8.0
3.5 12.6 10.4 0.83 1.55 8.1 16.2 129.5 5.2 425 12.6 1.56 8.1
120 3.7 12.6 10.4 0.82 1.54 8.2 16.3 128.8 5.8 425 12.6 1.56 8.1
4.0 12.6 10.4 0.82 1.54 8.2 16.3 128.2 6.4 425 12.6 1.55 8.1
4.2 12.7 10.4 0.82 1.53 8.3 16.3 127.7 7.1 425 12.7 1.55 8.2
4.5 12.7 10.4 0.82 1.53 8.3 16.3 127.4 7.8 425 12.7 1.55 8.2
