GECA 015 –
Heating – I-P
Performance
Data
Tabulated performance data is tabulated for heating at 68 F [20 C] DB entering air at ARI-ISO 13256-1 rated CFM.
Multipliers must be used to correct performance at conditions other than those tabulated. Data shown in
BOLD
type is performance and
multipliers at ARI-ISO 13256-1 WLHP and GLHP conditions.
RATED GPM: 3.6 MINIMUM CFM: 400 RATED CFM: 480 MAXIMUM CFM: 480
Table PD-11 – 015 Heating Performance
Htg Cap Absorb Power Ft. ISO Cap ISO Pwr ISO
EWT GPM Mbtuh Mbtuh kW COP LWT Hd CFM Mbtuh kW COP
2.5 8.4 6.6 0.91 2.7 17.5 3.6 425 8.4 0.91 2.7
3.0 8.8 7.0 0.92 2.8 19.0 4.8 425 8.8 0.93 2.8
3.5 9.2 7.3 0.94 2.9 20.3 6.1 425 9.2 0.95 2.8
25 3.7 9.3 7.4 0.94 2.9 20.8 6.8 425 9.3 0.96 2.8
4.0 9.4 7.6 0.95 2.9 21.3 7.6 425 9.4 0.97 2.9
4.2 9.6 7.7 0.96 2.9 21.6 8.3 425 9.6 0.98 2.9
4.5 9.7 7.8 0.96 3.0 21.9 9.2 425 9.7 0.99 2.9
2.5 9.9 8.0 0.97 3.0 26.7 3.6 425 9.9 0.97 3.0
3.0 10.3 8.4 0.99 3.1 28.3 4.8 425 10.3 0.99 3.0
3.5 10.6 8.7 1.00 3.1 29.6 6.1 425 10.6 1.01 3.1
35 3.7 10.8 8.9 1.01 3.1 30.1 6.8 425 10.8 1.02 3.1
4.0 10.9 9.0 1.01 3.2 30.5 7.6 425 10.9 1.03 3.1
4.2 11.0 9.1 1.02 3.2 30.9 8.4 425 11.0 1.04 3.1
4.5 11.1 9.2 1.02 3.2 31.2 9.2 425 11.1 1.05 3.1
2.5 11.8 9.9 1.05 3.3 37.1 3.5 425 11.8 1.05 3.3
3.0 12.1 10.1 1.06 3.3 38.3 4.8 425 12.1 1.07 3.3
3.5 12.3 10.3 1.07 3.4 39.1 6.1 425 12.3 1.08 3.3
45 3.7 12.3 10.4 1.07 3.4 39.5 6.8 425 12.3 1.09 3.3
4.0 12.4 10.5 1.07 3.4 39.8 7.6 425 12.4 1.09 3.3
4.2 12.5 10.6 1.08 3.4 40.1 8.4 425 12.5 1.10 3.3
4.5 12.6 10.6 1.08 3.4 40.3 9.2 425 12.6 1.11 3.3
2.5 13.0 11.0 1.10 3.4 45.2 3.6 425 13.0 1.11 3.4
3.0 13.5 11.6 1.12 3.5 47.3 4.8 425 13.5 1.13 3.5
3.5 13.8 11.8 1.13 3.6 48.3 6.1 425 13.8 1.15 3.5
55 3.7 13.9 11.9 1.14 3.6 48.7 6.8 425 13.9 1.15 3.5
4.0 14.0 12.0 1.14 3.6 49.0 7.6 425 14.0 1.16 3.5
4.2 14.1 12.1 1.15 3.6 49.3 8.3 425 14.1 1.17 3.5
4.5 14.2 12.2 1.15 3.6 49.6 9.2 425 14.2 1.17 3.5
2.5 15.2 13.2 1.19 3.7 57.4 3.5 425 15.2 1.20 3.7
3.0 15.6 13.6 1.21 3.8 58.9 4.7 425 15.6 1.22 3.7
3.5 15.9 13.9 1.22 3.8 60.1 6.1 425 15.9 1.24 3.8
68 3.7 16.0 14.0 1.23 3.8 60.5 6.8 425 16.0 1.24 3.8
4.0 16.2 14.1 1.23 3.8 60.9 7.6 425 16.2 1.25 3.8
4.2 16.3 14.2 1.24 3.8 61.3 8.3 425 16.3 1.26 3.8
4.5 16.4 14.4 1.25 3.8 61.6 9.1 425 16.4 1.28 3.8
2.5 16.6 14.6 1.26 3.9 65.3 3.5 425 16.6 1.26 3.9
3.0 17.1 15.0 1.27 3.9 66.9 4.7 425 17.1 1.28 3.9
3.5 17.4 15.4 1.29 4.0 68.2 6.1 425 17.4 1.30 3.9
77 3.7 17.6 15.5 1.30 4.0 68.7 6.8 425 17.6 1.31 3.9
4.0 17.7 15.6 1.30 4.0 69.1 7.5 425 17.7 1.32 3.9
4.2 17.8 15.8 1.31 4.0 69.5 8.3 425 17.8 1.33 3.9
4.5 17.9 15.9 1.31 4.0 69.9 9.1 425 17.9 1.34 3.9
2.5 18.1 16.0 1.32 4.0 73.1 3.5 425 18.1 1.32 4.0
3.0 18.6 16.5 1.34 4.1 74.9 4.7 425 18.6 1.35 4.0
3.5 18.9 16.9 1.36 4.1 76.3 6.1 425 18.9 1.37 4.1
86 3.7 19.1 17.0 1.36 4.1 76.8 6.8 425 19.1 1.38 4.1
4.0 19.3 17.2 1.37 4.1 77.3 7.5 425 19.3 1.39 4.1
4.2 19.4 17.3 1.38 4.1 77.8 8.3 425 19.4 1.40 4.1
4.5 19.6 17.5 1.38 4.1 78.2 9.1 425 19.6 1.41 4.1
Table 12 – Fan Correction Factors – Model GECA 015
Entering Cooling Sensible Cooling Input Heating Heating Input
CFM Capacity Capacity Watts Capacity Watts
333 0.953 0.915 0.989 0.964 1.071
425 1.000 1.000 1.000 1.000 1.000
