86 WSHP-PRC001-EN
E2-Electrical performance (continued)
Model
No.
Volts Total
FLA
Comp
RLA
(ea)
Comp
LRA
(ea)
No. of
Com-
pres.
Cmp
MCC
Blower
Motor
FLA
Blower
Motor
HP
Fan
Motor
Num
Minimum
Circuit
Ampacity
Maximum
Overcur-
rent
Protective
Device
Electric
Heat
kW
Electric
Heat
Amps
030 208/60/1 14.2 12.40 61.0 1 17.4 2.10 1/3 1 17.6 30 0 0
208/60/1 21.5 12.4 61.0 1 17.4 2.10 1/3 1 27.3 30 4.10 19.7
230/60/1 14.2 12.40 61.0 1 17.4 2.10 1/3 1 17.6 30 0 0
230/60/1 23.5 12.4 61.0 1 17.4 2.10 1/3 1 29.8 30 5.00 21.7
220-240/50/1 16.4 13.60 64.0 1 19.1 2.77 1/2 1 19.8 30 0 0
220-240/50/1 29.97 13.6 64.0 1 19.1 2.77 1/2 1 37.5 40 6.52 27.2
265/60/1 12.4 10.90 58.0 1 15.3 1.53 1/3 1 15.2 25 0 0
265/60/1 26.43 10.9 58.0 1 15.3 1.53 1/3 1 33.0 35 6.60 24.9
208/60/3 9.5 7.70 55.0 1 10.8 1.80 1/3 1 11.4 15 0 0
208/60/3 13.2 7.7 55.0 1 10.8 1.80 1/3 1 16.5 20 4.10 11.4
230/60/3 9.5 7.70 55.0 1 10.8 1.80 1/3 1 11.4 15 0 0
230/60/3 14.4 7.7 55.0 1 10.8 1.80 1/3 1 18.0 20 5.00 12.6
380-415/50/3 6.6 4.90 33.0 1 6.9 1.70 1/2 1 7.8 15 0 0
380-415/50/3 10.8 4.9 33.0 1 6.9 1.70 1/2 1 13.5 15 6.52 9.1
460/60/3 5.0 4.00 28.0 1 5.6 0.95 1/3 1 6.0 15 0 0
460/60/3 9.25 4.0 28.0 1 5.6 0.95 1/3 1 11.6 15 6.60 8.3
036 208/60/1 19.3 16.00 82.0 1 22.4 3.60 1/2 1 23.6 35 0 0
208/60/1 26.87 16.0 82.0 1 22.4 3.60 1/2 1 34.0 35 4.90 23.6
230/60/1 19.3 16.00 82.0 1 22.4 3.60 1/2 1 23.6 35 0 0
230/60/1 29.37 16.0 82.0 1 22.4 3.60 1/2 1 37.1 40 6.00 26.1
265/60/1 16.4 13.60 64.0 1 19.1 2.77 1/2 1 19.8 30 0 0
265/60/1 32.77 13.6 64.0 1 19.1 2.77 1/2 1 41.0 45 7.95 30.0
208/60/3 13.7 10.40 65.5 1 14.6 3.60 1/2 1 16.6 25 0 0
208/60/3 16.87 10.4 65.5 1 14.6 3.60 1/2 1 21.5 25 4.90 13.6
230/60/3 13.7 10.40 65.5 1 14.6 3.60 1/2 1 16.6 25 0 0
230/60/3 18.37 10.4 65.5 1 14.6 3.60 1/2 1 23.4 25 6.00 15.1
380-415/50/3 6.5 4.80 40.0 1 6.7 1.70 1/2 1 7.7 15 0 0
380-415/50/3 11.6 4.8 40.0 1 6.7 1.70 1/2 1 14.5 15 7.15 9.9
460/60/3 6.6 4.90 33.0 1 6.9 1.70 1/2 1 7.8 15 0 0
460/60/3 11.7 4.9 33.0 1 6.9 1.70 1/2 1 14.6 15 7.95 10.0
GEVA040 208/60/1 19.4 16.1 82.0 1 22.5 3.60 1/2 1 23.6 35 0 0
208/60/1 29.27 16.1 82.0 1 22.5 3.60 1/2 1 37.0 40 5.40 26.0
230/60/1 19.4 16.1 82.0 1 22.5 3.60 1/2 1 23.7 35 0 0
230/60/1 31.97 16.1 82.0 1 22.5 3.60 1/2 1 40.4 45 6.60 28.7
265/60/1 17.8 15.0 83.0 1 21.0 2.77 1/2 1 21.5 35 0 0
265/60/1 35.97 15.0 83.0 1 0.0 2.77 1/2 1 45.0 45 8.80 33.2
208/60/3 13.3 10.0 70.0 1 14.0 3.60 1/2 1 16.1 25 0 0
208/60/3 18.27 10.0 70.0 1 14.0 3.60 1/2 1 23.3 25 5.40 15.0
230/60/3 13.3 10.0 70.0 1 14.0 3.60 1/2 1 16.1 25 0 0
230/60/3 19.87 10.0 70.0 1 14.0 3.60 1/2 1 25.3 25 6.60 16.6
460/60/3 6.8 5.1 33.0 1 7.1 1.70 1/2 1 8.1 15 0 0
460/60/3 12.7 5.1 33.0 1 7.1 1.70 1/2 1 15.9 20 8.80 11.0
042 208/60/1 21.3 18.00 96.0 1 25.2 3.60 1/2 1 26.1 40 0 0
208/60/1 30.67 18.0 96.0 1 25.2 3.60 1/2 1 38.8 40 5.70 27.4
230/60/1 21.3 18.00 96.0 1 25.2 3.60 1/2 1 26.1 40 0 0
230/60/1 33.67 18.0 96.0 1 25.2 3.60 1/2 1 42.5 45 7.00 30.4
208/60/3 14.7 11.40 75.0 1 16.0 3.60 1/2 1 17.9 25 0 0
208/60/3 19.07 11.4 75.0 1 16.0 3.60 1/2 1 24.3 25 5.70 15.8
230/60/3 14.7 11.40 75.0 1 16.0 3.60 1/2 1 17.9 25 0 0
230/60/3 20.87 11.4 75.0 1 16.0 3.60 1/2 1 26.5 30 7.00 17.6
380-415/50/3 9.1 6.40 42.0 1 8.9 2.70 1 1 10.7 15 0 0
380-415/50/3 14.7 6.4 42.0 1 8.9 2.70 1 1 18.4 20 8.60 12.0
460/60/3 6.5 4.80 40.0 1 6.7 1.70 1/2 1 7.7 15 0 0
460/60/3 13.4 4.8 40.0 1 6.7 1.70 1/2 1 16.8 20 9.30 11.7
575/60/3 5.4 4.10 31.0 1 5.7 1.31 1/2 1 6.4 15 0 0
