WSHP-PRC001-EN 87
E3-Electrical performance (continued)
Model
No.
Volts Total
FLA
Comp
RLA
(ea)
Comp
LRA
(ea)
No. of
Com-
pres.
Cmp
MCC
Blower
Motor
FLA
Blower
Motor
HP
Fan
Motor
Num
Minimum
Circuit
Ampacity
Maximum
Overcur-
rent
Protective
Device
Electric
Heat
kW
Electric
Heat
Amps
048 208/60/1 25.8 20.40 102.0 1 28.5 5.40 1 1 30.9 50 0 0
208/60/1 36.7 20.4 102.0 1 28.5 5.40 1 1 45.9 50 6.50 31.3
230/60/1 25.8 20.40 102.0 1 28.5 5.40 1 1 30.9 50 0 0
230/60/1 40.2 20.4 102.0 1 28.5 5.40 1 1 50.3 60 8.00 34.8
208/60/3 19.4 14.00 91.0 1 19.7 5.40 1 1 22.9 35 0 0
208/60/3 23.4 14.0 91.0 1 19.7 5.40 1 1 29.3 35 6.50 18.0
230/60/3 19.4 14.00 91.0 1 19.7 5.40 1 1 22.9 35 0 0
230/60/3 25.5 14.0 91.0 1 19.7 5.40 1 1 31.9 35 8.00 20.1
380-415/50/3 10.2 7.50 49.5 1 10.5 2.70 1 1 12.1 15 0 0
380-415/50/3 14.7 7.5 49.5 1 10.5 2.70 1 1 18.4 20 8.60 12.0
460/60/3 9.1 6.40 42.0 1 8.9 2.70 1 1 10.7 15 0 0
460/60/3 16.0 6.4 42.0 1 8.9 2.70 1 1 20.0 25 10.60 13.3
575/60/3 7.4 5.20 39.0 1 7.3 2.20 1 1 8.7 15 0 0
060 208/60/1 33.4 28.00 169.0 1 39.0 5.40 1 1 40.4 60 0 0
208/60/1 36.7 28.0 169.0 1 39.0 5.4 1 1 45.9 60 6.50 31.3
230/60/1 33.4 28.00 169.0 1 35.0 5.40 1 1 40.4 60 0 0
230/60/1 40.2 28.0 169.0 1 39.0 5.4 1 1 50.3 60 8.00 34.8
208/60/3 25.4 20.00 123.0 1 28.0 5.40 1 1 30.4 50 0 0
208/60/3 25.4 20.0 123.0 1 27.0 5.4 1 1 30.4 50 6.50 18.0
230/60/3 25.4 20.00 123.0 1 28.0 5.40 1 1 30.4 50 0 0
230/60/3 25.5 20.0 123.0 1 27.0 5.4 1 1 31.9 50 8.00 20.1
380-415/50/3 12.8 10.00 62.0 1 14.0 2.70 1 1 15.2 25 0 0
380-415/50/3 14.7 10.0 62.0 1 14.0 2.7 1 1 18.4 25 8.60 12.0
460/60/3 10.2 7.50 49.5 1 10.5 2.70 1 1 12.1 15 0 0
460/60/3 16.0 7.5 49.5 1 10.5 2.7 1 1 20.0 25 10.60 13.3
575/60/3 8.6 6.40 40.0 1 9.0 2.20 1 1 10.2 15 0 0
150 208/60/3 45.7 19.30 137.0 2 27.0 7.10 2 1 50.5 60
230/60/3 44.8 19.30 137.0 2 27.0 6.20 2 1 49.6 60
380-420/50/3 23 10.00 64.0 2 14.0 3.00 1.5 1 25.5 35
460/60/3 23.11 10.00 62.0 2 14.0 3.11 2 1 25.6 35
575/60/3 18 7.85 50.0 2 11.0 2.30 2 1 20.0 25
208/60/3 48 19.30 137.0 2 27.0 9.40 3 1 52.8 70
230/60/3 46.8 19.30 137.0 2 27.0 8.20 3 1 51.6 70
380-420/50/3 23.4 10.00 64.0 2 14.0 3.40 2 1 25.9 35
460/60/3 24.1 10.00 62.0 2 14.0 4.10 3 1 26.6 35
575/60/3 19 7.85 50.0 2 11.0 3.30 3 1 21.0 25
208/60/3 54.6 19.30 137.0 2 27.0 16.00 5 1 59.4 70
230/60/3 52.6 19.30 137.0 2 27.0 14.00 5 1 57.4 70
380-420/50/3 25.5 10.00 64.0 2 14.0 5.50 3 1 28.0 35
460/60/3 27 10.00 62.0 2 14.0 7.00 5 1 29.5 35
575/60/3 20.9 7.85 50.0 2 11.0 5.20 5 1 22.9 30
180 208/60/3 59.4 25.00 164.0 2 35.0 9.40 3 1 65.7 90
230/60/3 58.2 25.00 164.0 2 35.0 8.20 3 1 64.5 80
380-420/50/3 27.4 12.00 90.5 2 17.0 3.40 2 1 30.4 40
460/60/3 28.1 12.00 100.0 2 17.0 4.10 3 1 31.1 40
575/60/3 21.9 9.30 78.0 2 13.0 3.30 3 1 24.2 30
208/60/3 66 25.00 164.0 2 35.0 16.00 5 1 72.3 90
230/60/3 64 25.00 164.0 2 35.0 14.00 5 1 70.3 90
380-420/50/3 29.5 12.00 90.5 2 17.0 5.50 3 1 32.5 40
460/60/3 31 12.00 100.0 2 17.0 7.00 5 1 34.0 45
575/60/3 23.8 9.30 78.0 2 13.0 5.20 5 1 26.1 35
208/60/3 75 25.00 164.0 2 35.0 25.00 7.5 1 81.3 100
230/60/3 71.6 25.00 164.0 2 35.0 21.60 7.5 1 77.9 100
380-420/50/3 33.3 12.00 90.5 2 17.0 9.30 5 1 36.3 45
460/60/3 34.8 12.00 100.0 2 17.0 10.80 7.5 1 37.8 45
575/60/3 26.8 9.30 78.0 2 13.0 8.20 7.5 1 29.1 35
Performance Data
Electrical
