Table 8. Dimensional data right return/back supply (GEHE)
GEH
Unit
(60 Hz)
GEH
Unit
(50 Hz)
A B C
D
(a)
E F x G H J K
L
NPTI
M
NPTI
N P
Q
R
(b)
S
006, 009
006 40 20 15 20 15
6-7/8 x 8 11-1/2 4-1/2 1-3/4 1/2 1/2 38-3/4 18-3/4 13-5/8 18-1/2 3-1/4
012, 015 009, 012
40 20 15 20 15
6-7/8 x 9-
7/8
11-1/2 4-1/4 3/4 1/2 1/2 38-3/4 18-3/4 13-5/8 18-1/2 3-1/4
018 015 46 23 18 23 18
8-1/4 x 9-
3/4
13-1/2 4-3/4 1-3/8 3/4 3/4 44-3/4 21-3/4 16-5/8 18-1/2 4-1/4
024, 030 018, 024
46 23 18 23 18
8-1/4 x 11-
3/8
13-1/2 4-3/4 1-3/8 3/4 3/4 44-3/4 21-3/4 16-5/8 18-1/2 4-1/4
035, 042 030, 036
50 25 19 25 20
10-1/2 x
13-1/2
17 4 1
3/4 3/4 48-3/4 23-3/4 17-5/8 23-1/2 3-1/4
Std-048 Std-042 58 33 21
29-1/
2
23-1/2
13-1/8 x
11-3/8
18
5-1/4 1-1/2
1 1
56-3/4 31-3/4 19-5/8 23-1/2 5-1/2
Hi-048,
060
Hi-042,
048, 060
58 33 21
29-1/
2
23-1/2
13-7/8 x
13-7/8
18
5-1/4 1-1/2
1 1
56-3/4 31-3/4 19-5/8 23-1/2 5-1/2
Note: Equipment containing a same-side supply/return combination requires a 3 in. clearance on one side. Access to the TXV may not be possible with this
3 in. clearance.
(a)
Return air opening dimension.
(b)
Filter rack dimension.
Figure 11. Right return/right supply (GEHE)
TOP
BACK
LEFT SIDE
FRONT
RIGHT SIDE
BP
N
A
C
H
H
E D
J
1"
K
DRAIN
3/4" NPTI
BLOWER
ACCESS
PANEL
F X G
OPENING
COMP/CONTROL
ACCESS
HI VOLT
LO VOLT
14"
Q
L (W.O.)
M (W.I.)
R
S
1"
1 3/8"
7
"
6 3/4"
1/2"
WCI mounting location
Table 9. Dimensional data right return/right supply (GEHE)
GEH
Unit
(60 Hz)
GEH
Unit
(50 Hz)
A B C
D
(a)
E F x G H J K
L
NPTI
M
NPTI
N P
Q
R
(b)
S
006, 009
006 40 20 15 20 15
6-7/8 x 8 11-1/2 4-1/2 1-3/4 1/2 1/2 38-3/4 18-3/4 13-5/8 18-1/2 3-1/4
012, 015 009, 012
40 20 15 20 15
6-7/8 x 9-
7/8
11-1/2 4-1/4 3/4 1/2 1/2 38-3/4 18-3/4 13-5/8 18-1/2 3-1/4
018 015 46 23 18 23 18
8-1/4 x 9-
3/4
13-1/2 4-3/4 1-3/8 3/4 3/4 44-3/4 21-3/4 16-5/8 18-1/2 4-1/4
024, 030 018, 024
46 23 18 23 18
8-1/4 x 11-
3/8
13-1/2 4-3/4 1-3/8 3/4 3/4 44-3/4 21-3/4 16-5/8 18-1/2 4-1/4
035, 042 030, 036
50 25 19 25 20
10-1/2 x
13-1/2
17 4 1
3/4 3/4 48-3/4 23-3/4 17-5/8 23-1/2 3-1/4
Std-048 Std-042 58 33 21
29-1/
2
23-1/2
13-1/8 x
11-3/8
18
5-1/4 1-1/2
1 1
56-3/4 31-3/4 19-5/8 23-1/2 5-1/2
Hi-048,
060
Hi-042,
048, 060
58 33 21
29-1/
2
23-1/2
13-7/8 x
13-7/8
18
5-1/4 1-1/2
1 1
56-3/4 31-3/4 19-5/8 23-1/2 5-1/2
Notes:
1. When a horizontal model is ordered with the same side return and supply in a ducted application, bottom filter removal is required due to limited
access on either side of the filter.
2. Equipment containing a same-side supply/return combination requires a 3 in. clearance on one side. Access to the TXV may not be possible with this 3
in. clearance.
(a)
Return air opening dimension.
(b)
Filter rack dimension.
