68
WSHP-SVX01AA-EN
Electrical Data
Table 48. Electrical data standard static motors (0.5 to 25 tons), single speed blower motor (6 to 25 tons)
Model No. Volts
Total
Unit FLA
Comp
RLA (ea)
Comp
LRA (ea)
No. of
Comp.
Blower
Motor
FLA
Blower
Motor hp
Fan
Motor
Num
Mini- mum
Circuit
Ampaci-
ty
Maxi-
mum
Overcur-
rent
Protec-
tive
Device
Electric
Heat kW
(a)
Electric
Heat
Amps
(a)
GEHE006
115/60/1
6.8 5.6 30.0 1 1.20
1/12
1 8.2 15 0.0 0.0
GEHE006
208/60/1
3.9 3.3 14.0 1 0.60
1/12
1 4.73 15 0.0 0.0
GEHE006
208/60/1
4.5 3.3 14.0 1 0.60
1/12
1 5.68 15 0.8 3.9
GEHE006
230/60/1
3.8 3.2 15.0 1 0.60
1/12
1 4.6 15 0.0 0.0
GEHE006
230/60/1
4.9 3.2 15.0 1 0.60
1/12
1 6.18 15 1.0 4.3
GEHE006
265/60/1
3.0 2.5 11.0 1 0.52
1/12
1 3.65 15 0.0 0.0
GEHE006
265/60/1
5.5 2.5 11.0 1 0.52
1/12
1 6.92 15 1.3 5.0
GEHE009
115/60/1
7.6 6.4 36.0 1 1.20
1/12
1 9.2 15 0.0 0.0
GEHE009
208/60/1
4.3 3.7 16.0 1 0.60
1/12
1 5.23 15 0.0 0.0
GEHE009
208/60/1
6.5 3.7 16.0 1 0.60
1/12
1 8.14 15 1.2 5.9
GEHE009
230/60/1
4.1 3.5 17.0 1 0.60
1/12
1 4.98 15 0.0 0.0
GEHE009
230/60/1
7.1 3.5 17.0 1 0.60
1/12
1 8.9 15 1.5 6.5
GEHE009
265/60/1
3.3 2.8 13.0 1 0.52
1/12
1 4.02 15 0.0 0.0
GEHE009
265/60/1
8.1 2.8 13.0 1 0.52
1/12
1 10.08 15 2.0 7.5
GEHE012
115/60/1
13.7 12.1 58.0 1 1.57
1/8
1 16.7 25 0.0 0.0
GEHE012
208/60/1
7.0 6.3 30.0 1 0.70
1/8
1 8.58 15 0.0 0.0
GEHE012
208/60/1
8.5 6.3 27.0 1 0.70
1/8
1 10.67 15 1.6 7.8
GEHE012
230/60/1
7.0 6.3 30.0 1 0.70
1/8
1 8.58 15 0.0 0.0
GEHE012
230/60/1
9.4 6.3 30.0 1 0.70
1/8
1 11.74 15 2.0 8.7
GEHE012
265/60/1
5.7 5.0 23.0 1 0.72
1/8
1 6.97 15 0.0 0.0
GEHE012
265/60/1
10.7 5.0 23.0 1 0.72
1/8
1 13.4 15 2.7 10.0
GEHE015
208/60/1
8.6 7.9 36.0 1 0.70
1/8
1 10.58 15 0.0 0.0
GEHE015
208/60/1
10.3 7.9 36.0 1 0.70
1/8
1 12.89 15 2.0 9.6
GEHE015
230/60/1
8.6 7.9 36.0 1 0.70
1/8
1 10.58 15 0.0 0.0
GEHE015
230/60/1
11.6 7.9 36.0 1 0.70
1/8
1 14.46 15 2.5 10.9
GEHE015
265/60/1
7.1 6.4 30.0 1 0.72
1/8
1 8.72 15 0.0 0.0
GEHE015
265/60/1
13.2 6.4 30.0 1 0.72
1/8
1 16.47 20 3.3 12.5
