Table 48. Electrical data standard static motors (0.5 to 25 tons), single speed blower motor (6 to 25 tons) (continued)
Model No. Volts
Total
Unit FLA
Comp
RLA (ea)
Comp
LRA (ea)
No. of
Comp.
Blower
Motor
FLA
Blower
Motor hp
Fan
Motor
Num
Mini- mum
Circuit
Ampaci-
ty
Maxi-
mum
Overcur-
rent
Protec-
tive
Device
Electric
Heat kW
(a)
Electric
Heat
Amps
(a)
GEHE018
208/60/1
10.5 9.6 42.0 1 0.90
1/8
1 12.9 20 0.0 0.0
GEHE018
208/60/1
12.7 9.6 42.0 1 0.90
1/8
1 15.91 20 2.5 11.8
GEHE018
230/60/1
10.5 9.6 42.0 1 0.90
1/8
1 12.9 20 0.0 0.0
GEHE018
230/60/1
13.9 9.6 42.0 1 0.90
1/8
1 17.43 20 3.0 13.0
GEHE018
265/60/1
8.5 7.7 35.0 1 0.80
1/8
1 10.43 15 0.0 0.0
GEHE018
265/60/1
15.9 7.7 35.0 1 0.80
1/8
1 19.87 20 4.0 15.1
GEHE024
208/60/1
14.9 12.8 58.3 1 2.10
1/3
1 18.1 30 0.0 0.0
GEHE024
208/60/1
17.8 12.8 58.3 1 2.10
1/3
1 22.22 30 3.3 15.7
GEHE024
230/60/1
14.9 12.8 58.3 1 2.10
1/3
1 18.1 30 0.0 0.0
GEHE024
230/60/1
19.5 12.8 58.3 1 2.10
1/3
1 24.36 30 4.0 17.4
GEHE024
265/60/1
11.1 9.6 54.0 1 1.53
1/3
1 13.53 20 0.0 0.0
GEHE024
265/60/1
21.5 9.6 54.0 1 1.53
1/3
1 26.91 30 5.3 20.0
GEHE024
208/60/3
9.2 7.7 53.7 1 1.53
1/3
1 11.16 15 0.0 0.0
GEHE024
208/60/3
10.6 7.7 53.7 1 1.53
1/3
1 13.22 15 3.3 9.0
GEHE024
230/60/3
9.8 7.7 53.7 1 2.10
1/3
1 11.73 15 0.0 0.0
GEHE024
230/60/3
12.1 7.7 53.7 1 2.10
1/3
1 15.18 20 4.0 10.0
GEHE024
460/60/3
4.6 3.6 28.0 1 0.95
1/3
1 5.45 15 0.0 0.0
GEHE024
460/60/3
7.6 3.6 28.0 1 0.95
1/3
1 9.5 15 5.3 6.7
GEHE030
208/60/1
16.2 14.1 73.0 1 2.10
1/3
1 19.73 30 0.0 0.0
GEHE030
208/60/1
21.8 14.1 73.0 1 2.10
1/3
1 27.26 30 4.1 19.7
GEHE030
230/60/1
16.2 14.1 73.0 1 2.10
1/3
1 19.73 30 0.0 0.0
GEHE030
230/60/1
23.8 14.1 73.0 1 2.10
1/3
1 29.8 30 5.0 21.7
GEHE030
265/60/1
12.7 11.2 60.0 1 1.53
1/3
1 15.53 25 0.0 0.0
GEHE030
265/60/1
26.4 11.2 60.0 1 1.53
1/3
1 33.04 35 6.6 24.9
GEHE030
208/60/3
11.0 8.9 58.0 1 2.10
1/3
1 13.23 20 0.0 0.0
GEHE030
208/60/3
13.5 8.9 58.0 1 2.10
1/3
1 16.85 20 4.1 11.4
GEHE030
230/60/3
11.0 8.9 58.0 1 2.10
1/3
1 13.23 20 0.0 0.0
EElleeccttrriiccaall DDaattaa
