WARNING
This manual, including the warnings and cautions inside, must be carefully read
and followed by all persons who use or maintain this product, including those who
have any responsibility involving its selection, application, service or repair. This
unit will perform as designed only if used and maintained according to the
instructions. Otherwise, it could fail to perform as designed and persons who rely
on this product could sustain serious personal injury or death.
Page Description
3 General Information
3 Receiving Instructions
3 Literature Change History
3 Warnings and Cautions
4 Arrangements B (10-80),
C (10-40), D (10-80),
E (10-40), G (20-40)
9 Arrangements C (50-80),
E (50-80), G (50-12), J (20-12),
K (10-80), L (10-80)
14 Ductwork Connection
Note: Digit 14 in the Model
Number determines the
arrangement of the unit.
Table of
Contents
Arrangement Unit Size Dimensional
Data
Roof
Opening
Roof Curb
Assembly
Curb
Spec’s.
Ductwork
Connection
B = Blower (Standard)
10-40 Page 4 Page 5 Page 6 Page 8
Page 14
50-80 Page 4 Page 5 Page 6 Page 8
C = Blower (Standard)
Plenum
10-40 Page 4 Page 5 Page 6 Page 8
50-80 Page 9 Page 10 Page 11 Page 13
D = Blower (Standard)
Evaporative Cooler
10-40 Page 4 Page 5 Page 6 Page 8
50-80 Page 4 Page 5 Page 6 Page 8
E = Blower (Standard)
Evaporative Cooler/Plenum
10-40 Page 4 Page 5 Page 6 Page 8
50-80 Page 9 Page 10 Page 11 Page 13
G = Blower (High CFM)
20-40 Page 4 Page 5 Page 6 Page 8
50-80 Page 9 Page 10 Page 11 Page 13
12 Page 9 Page 10 Page 11 Page 13
J = Blower (High CFM)
Plenum
20-40 Page 9 Page 10 Page 11 Page 13
50-80 Page 9 Page 10 Page 11 Page 13
12 Page 9 Page 10 Page 11 Page 13
K = Blower (High CFM)
Cooling
10-40 Page 9 Page 10 Page 11 Page 13
50-80 Page 9 Page 10 Page 11 Page 13
L = Blower (High CFM)
Cooling / Plenum
10-40 Page 9 Page 10 Page 11 Page 13
50-80 Page 9 Page 10 Page 11 Page 13
