Trane IntelliPak Signature Series Programming Guide

6 PKG-SVP01B-EN
General
InformationProgramming
Table P-GI-1. IntelliPak
®
Points List.
Unit Module Analog Inputs Analog Outputs Binary Inputs Binary Outputs
RTM ASE damper min pos O/A damper actuator Emergency stop VAV box drive max
External auto/stop CV unoccupied mode indicator
Unoccupied/occupied Alarm
Dirty filter Fan run request
VAV changeover Water pump request
Supply airflow proof
SCM Evap temp sensor Cond fan speed Low pressure control Compressor relay
Sat cond temp sensor (Low ambient) Compressor proving Condenser fan A, B
MCM Evap temp sensor Cond fan speed Low pressure control - ckt 1 & 2 Compressor relay
Sat cond temp sensor (Low ambient - ckt 1 & 2) Compressor proving - ckt 1 & 2 Condenser fan 1A, 1B, 2A, 2B
Heat Module MWU temp sensor Modulating heat actuator Low entering air Heat 1 relay
Heat 2 relay
Heat 3 relay
ECEM Return air temp sensor
Return air humidity sensor
VOM N/A N/A VOM mode A, B, C, D, E contacts VOM relay
GBAS 4 inputs from these choices: N/A Demand limit contacts Dirty filter
Occ zone cool setpt Refrigeration fail relay
Occ zone heat setpt Heat fail relay
Unocc zone cooling setpt Fan fail relay
Unocc zone heat set TBD relay
Min O/A flow setpt
Sup air cooling setpt
Sup air heating setpt
Sup air static pres setpt
