Trane IntelliPak Signature Series Programming Guide

64
Programming
PKG-SVP01B-EN
(On all water-cooled units and water flow switch or units with a waterside
economizer and water flow switch)
Configuration - Model Num Digit 29
Water Flow Switch INSTALLED
Possible Values: Installed
Not Installed
1. Pressing the NEXT key will display the following screen.
Configuration - Model Num Digit 20
Heating Type HYDRONIC
Possible Values: Hydronic
Electric
None
External
1. Pressing the NEXT key will display the following screen.
Configuration - Model Num Digit 6, 7
Unit Capacity 72
Possible Values: 20-80
Note: The possible value for unit capacity is dependent upon the unit size (tons).
1. Pressing the NEXT key will display the following screen.
Configuration - Model Num Digit 23
Power Exhaust NONE
Possible Values: None
100% with Statitrac
50%/100% without Statitrac
Note: This option is currently not available on commercial self-contained units, but this
screen still displays.
1. Pressing the NEXT key will display the following screen.
Configuration - Model Num Digit 28
Air Economizer INSTALLED
Possible Values: Installed
Not Installed
1. Pressing the NEXT key will display the following screen.
CONFIGURATION
