Trane IntelliPak Programming Guide

56 RT-SVP011A-EN
Troubleshooting
VFD Fault Relief
Fan - x
VFD Fault Relief
Fan - x
VFD Fault Relief
Fan - x
Unit Normal
Shutdown with
Special Action
Latching All VFD Fault. Numerous drive faults can cause this general
fault. Reference the EBM-PAPST Installation and
Operating manual for a list of fault codes and
descriptions. (Clears on Reset)
Other fans available: Warning only.
No fans available: Relief damper is closed, relief fan
commanded off and the Economizing will be disable and
the outside air damper will be driven to the active
minimum position.
The Latching behavior for this diagnostic is latched in the
drive. When the drive diagnostics are reset this diagnostic
will be cleared in the Symbio 800 controller.
Local
VFD Relief Fan
Locked Motor - x
VFD Relief Fan
Locked Motor - x
VFD Relief Fan
Lock Motor - x
Unit Normal
Shutdown with
Special Action
Latching All Something has blocked the rotor from turning. Ice is a
common one in some applications. (Motor Auto Reset)
Other fans available: Warning only.
No fans available: Relief damper is closed, relief fan
commanded off and the Economizing will be disable and
the outside air damper will be driven to the active
minimum position.
The Latching behavior for this diagnostic is latched in the
drive. When the drive diagnostics are reset this
diagnostic will be cleared in the Symbio 800 controller.
Local
VFD Relief Fan
Motor
Overheated – x
VFD Relief Fan
Motor
Overheated – x
VFD Relief Fan
Motor Overheat –
x
Unit Normal
Shutdown with
Special Action
Latching All The motor thermocouples have reached a too-high
temperature. Typically caused by excessively high
ambient temp. (Motor Manual Reset)
Other fans available: Warning only.
No fans available: Relief damper is closed, relief fan
commanded off and the Economizing will be disable and
the outside air damper will be driven to the active
minimum position.
The Latching behavior for this diagnostic is latched in the
drive. When the drive diagnostics are reset this
diagnostic will be cleared in the Symbio 800 controller.
Local
VFD Relief Fan
Power Mod
Overheated – x
VFD Relief Fan
Power Mod
Overheated – x
VFD PM Overheat
Relief Fan – x
Unit Normal
Shutdown with
Special Action
Latching All The Rectifier thermocouple has reached a too-high
temperature. Typically caused by excessively high
ambient temp. (Motor Manual Reset)
Other fans available: Warning only.
No fans available: Relief damper is closed, relief fan
commanded off and the Economizing will be disable and
the outside air damper will be driven to the active
minimum position.
The Latching behavior for this diagnostic is latched in the
drive. When the drive diagnostics are reset this diagnostic
will be cleared in the Symbio 800 controller.
Local
VFD Relief Fan
Speed Parameter
Failure – x
VFD Relief Fan
Speed Parameter
Failure – x
VFD Relief Fan
Speed Param Fail
– x
Unit Normal
Shutdown with
Special Action
Latching All The motors Maximum Speed parameter does not match
the Maximum Permissible Speed parameter. (EC-Clone
Required)
Other fans available: Warning only.
No fans available: Relief damper is closed, relief fan
commanded off and the Economizing will be disable and
the outside air damper will be driven to the active
minimum position.
The Latching behavior for this diagnostic is latched in the
drive. When the drive diagnostics are reset this diagnostic
will be cleared in the Symbio 800 controller.
Local
Diagnostic Name
and Source
Affects
Target
Severity Persistence
Active
Modes
[Inactive
Modes]
Criteria
Reset
Level
