Trane IntelliPak - Page 77

RT-SVP011A-EN 77
Troubleshooting
Comm Loss:
Suction
Temperature 1
Cktx
Comm Loss:
Suction
Temperature 1
Cktx
Comm Loss:
Suction Temp
Circuit Immediate
Shutdown
Latching All Continual loss of communication between the MP and the
Functional ID has occurred for a 30 second period.
Remote
Comm Loss:
Suction
Temperature 2
Cktx
Comm Loss:
Suction
Temperature 2
Cktx
Comm Loss:
Suction Temp
Circuit Immediate
Shutdown
Latching All Continual loss of communication between the MP and the
Functional ID has occurred for a 30 second period.
Remote
Comm Loss:
Suction Pressure
Cktx
Comm Loss:
Suction Pressure
Cktx
Comm Loss:
Suction Press
Circuit Immediate
Shutdown
Non-Latching All Continual loss of communication between the MP and the
Functional ID has occurred for a 30 second period.
Remote
Comm Loss :
Discharge
Pressure Cktx
Comm Loss :
Discharge
Pressure Cktx
Comm Loss :
Disch Press Cktx
Circuit Immediate
Shutdown
Latching All Continual loss of communication between the MP and the
Functional ID has occurred for a 30 second period.
Remote
Comm Loss:
Condenser Fan
Relay 1 Cktx
Comm Loss:
Cond Fan Relay 1
Cktx
Comm Loss: Fan
Relay
Circuit Immediate
Shutdown
Latching All Continual loss of communication between the MP and the
Functional ID has occurred for a 30 second period.
Remote
Comm Loss:
Condenser Fan
Relay 2 Cktx
Comm Loss:
Cond Fan Relay 2
Cktx
Comm Loss: Fan
Relay
Circuit Immediate
Shutdown
Latching All Continual loss of communication between the MP and the
Functional ID has occurred for a 30 second period.
Remote
Comm Loss:
Condenser Fan
Relay 3 Cktx
Comm Loss:
Cond Fan Relay 3
Cktx
Comm Loss: Fan
Relay
Circuit Immediate
Shutdown
Latching All Continual loss of communication between the MP and the
Functional ID has occurred for a 30 second period.
Remote
Diagnostic Name
and Source
Affects
Target
Severity Persistence
Active
Modes
[Inactive
Modes]
Criteria
Reset
Level
