Trane IntelliPak Programming Guide

80 RT-SVP011A-EN
Troubleshooting
Comm Loss:
Return Air
Isolation Damper
Comm Loss:
Return Air
Isolation Damper
Comm: RA Iso
Damper
Unit Immediate
Shutdown
Latching All Continual loss of communication between the MP and the
Return Air Isolation Damper has occurred for a 30 second
period.
Remote
Comm Loss:
Condensate
Overflow
Comm Loss:
Condensate
Overflow
Comm:
Condensate
Overflow
Unit Immediate
Shutdown
with Special
Action
Latching All Continual loss of communication between the MP and the
Condensate Overflow status has occurred for a 30 second
period.
VOM Behavior: During VOM this diagnostic changes
behavior to a latching warning diagnostic. See the
Condensate Overflow Protection specification for more
information.
Remote
Comm Loss:
Outdoor Air
Damper
Comm Loss:
Outdoor Air
Damper
Comm: OA
Damper
Unit Warning with
Special Action
Non- Latching All Continual loss of communication between the MP and the
Outdoor Air Damper has occurred for a 30 second period.
Disable Economizer function.
Remote
Comm Loss:
Outdoor Air
Damper
Feedback
Comm Loss:
Outdoor Air
Damper
Feedback
Comm: OA
Damper
Feedback
Unit Warning with
Special Action
Non- Latching All Continual loss of communication between the MP and the
Outdoor Air Damper Feedback has occurred for a 30
second period.
Disable Economizer function.
Remote
Comm Loss:
Relief Air Damper
Comm Loss:
Relief Air Damper
Comm: Relief
Damper
Unit Warning with
Special Action
Non- Latching All Continual loss of communication between the MP and the
Relief Air Damper has occurred for a 30 second period.
Disable Space Pressure Control.
Unit
Comm Loss:
Relief Air Damper
Feedback
Comm Loss:
Relief Air Damper
Feedback
Comm: Relief
Damper
Feedback
Unit Warning Non- Latching All Continual loss of communication between the MP and the
Relief Air Damper Feedback has occurred for a 30 second
period.
Unit
Comm Loss:
Staged Electric
Heat Relay 1
Comm Loss:
Staged Electric
Heat Relay 1
Comm: Staged
Elec Heat Relay
Unit Normal
Shutdown
Latching All Continual loss of communication between the MP and the
Functional ID has occurred for a 30 second period.
Remote
Diagnostic Name
and Source
Affects
Target
Severity Persistence
Active
Modes
[Inactive
Modes]
Criteria
Reset
Level
