Connection to the drains
Direct connection to the drains of the building
of the building
WARNING! The water discharged from the
humidifier is at a very high temperature.
The drainage tube has to withstand high
temperatures (at least 100°C) and must be kept
away from electrical cables.
Connection to the gas drain
U7
U4
DIGITAL CONFIGURABLE INPUTS
Terminal board 51-20
- User
- ON - OFF Remote
- Flooding sensor (SAS)
Terminal board 52-20
- User
- ON-OFF Remote
- Fire-smoke (SFF)
Terminal board 50-20
- User
- ON-OFF Remote
- Tools (ATA-BTA-AUA-BUA)
Drain
Drain
