Trane P0V0 Series Installer's Guide

18
18-GE20D1-1E-EN
Table 8. Return Duct Connections (continued)
Upflow Modular Blower with Bottom Return Mounted on a
Ducted Pedestal
1. Remove the bottom plate.
2. Set the modular blower on the ducted pedestal. The ducted
pedestal will use ducted air from a remote location.
3. Install filter at a remote location.
4. Seal per local codes and requirements.
Upflow Modular Blower with Bottom Return Mounted on a
Ducted Pedestal with Filter Box
1. Remove the bottom plate.
2. Set the modular blower on the filter box. The ducted pedestal will
use ducted air from a remote location.
3. Seal per local codes and requirements.
FILTER
GGeenneerraall IInnssttaallllaattiioonn
