Trane R-410A Split System - Capacity Tables; 60 Hz Model Capacity Data

&DSDFLW\7DEOHV
Model
SUMMER
Indoor conditions
25ć 30ć 35ć 40ć 45ć 50ć
Total Capacity (Btu/h)
9025 8636 7879 7159 7903 7643
Sensible Capacity (Btu/h)
6770 6572 6084 5606 6275 6152
Input (W)
647 684 703 797 1026 1119
Compressor Frequency (Hz)
54 54 54 54 54 54
Total Capacity (Btu/h)
9588 9240 8575 7742 8687 8319
Sensible Capacity (Btu/h)
7142 6947 6507 5930 6715 6490
Input (W)
665 695 729 815 1052 1147
Compressor Frequency (Hz)
54 54 54 54 54 54
Total Capacity (Btu/h)
10161 9721 8800 8455 9281 8462
Sensible Capacity (Btu/h)
7660 7408 7067 6579 7295 6719
Input (W)
677 715 760 855 1087 1172
Compressor Frequency (Hz)
54 54 54 54 54 54
Total Capacity (Btu/h)
10421 10540 9984 9619 10438 9936
Sensible Capacity (Btu/h)
7712 7957 7688 7551 8350 8097
Input (W)
683 723 785 884 1172 1238
Compressor Frequency (Hz)
54 54 54 54 54 54
WINTER
12ć D7ć D4ć D0ć D-4ć D-7ć D
11ć W6ć W3ć W-1ć W-6ć W-8ć W
Total Capacity (Btu/h)
11436 10308 12106 12854 11282 10021
Input (W)
736 610 894 1190 1159 1142
Compressor Frequency (Hz)
57 57 57 57 57 57
Total Capacity (Btu/h)
10418 9279 11662 12571 11204 9621
Input (W)
765 644 928 1221 1185 1165
Compressor Frequency (Hz)
57 57 57 57 57 57
Total Capacity (Btu/h)
10209 8900 11457 12431 11101 9679
Input (W)
771 650 939 1230 1194 1167
Compressor Frequency (Hz)
57 57 57 57 57 57
Total Capacity (Btu/h)
9679 8685 10893 12106 11193 9563
Input (W)
808 659 989 1281 1235 1240
Compressor Frequency (Hz)
57 57 57 57 57 57
15ć
18
ć
20ć
22ć
27ć D 19ć W
32ć D 23ć W
OUTDOOR TEMPERATURE DRY
Indoor conditions
4MYW5509A1/4TYK5509A1
4MXW5509A1/4TXK5509A1
OUTDOOR TEMPERATURE DRY
21ć D 15ć W
24ć D 17ć W
20
